Red Hat Enterprise Linux

Overview

The Red Hat Enterprise Linux (RHEL) integration in Motadata AIOps provides comprehensive monitoring capabilities for RHEL-based systems. By capturing and analyzing critical performance data, system logs, and metrics from RHEL devices and servers, this integration offers valuable insights into the health and performance of the RHEL infrastructure. With real-time visibility, administrators can proactively detect and resolve potential issues, optimize resource allocation, and ensure the smooth and secure operation of their RHEL environment, promoting overall stability and productivity.

Prerequisites

Kindly refer the prerequisites for Adding Linux Servers for Monitoring here.

List of Supported KPIs

RHEL

Metrics	Description	Type
system.network.in.bytes.rate		Rate
system.overall.memory.free.bytes	The amount of free space available in RAM on your host.	Bytes
system.load.avg15.min	The average system load over fifteen minutes. (available for Linux only)	Percentage
system.cpu.type
system.swap.memory.free.bytes	The amount of free swap space.	Bytes
system.swap.memory.used.percent	The percentage of used swap memory in your system.	Percentage
system.vendor	The name of the vendor for the monitoring device	String
system.load.avg1.min	The average system load over one minute. (available for Linux only)	Percentage
system.network.udp.connections	The total number of UDP connections.	Count
system.load.avg5.min	The average system load over five minutes. (available for Linux only)	Percentage
system.blocked.processes	The number of blocked processes in the system.	Count
system.opened.file.descriptors	The number of file descriptors used by a particular process.	Count
system.cache.memory.bytes	The amount of the RAM used as cache memory.	Bytes
system.swap.memory.provisioned.bytes		Bytes
system.disk.io.time.percent	The percentage of time spent reading or writing to the disk	Percentage
system.network.tcp.connections	The total number of TCP connections.	Count
system.virtual
system.cpu.cores	The number of CPU cores on your host.	Count
system.os.name	The name of the operating system on your host.	String
system.os.version	The version of the operating system on your host.	String
system.context.switches.per.sec	The number of context switches per second.	Rate
system.disk.capacity.bytes	The capacity of the disk.	Bytes
system.network.tcp.retransmissions	The count of lost or damaged packets that were resent over the network.	Count
system.buffer.memory.bytes	The amount of the RAM used as buffer memory.	Bytes
system.swap.memory.used.bytes	The amount of used swap space in your system.	Bytes
system.cpu.interrupt.percent	The percentage of time the CPU has spent servicing hardware interrupts
system.memory.available.bytes	The amount of free RAM.	Bytes
system.interrupts.per.sec	The number of CPU interrupts per second.	Rate
system.overall.memory.used.bytes	The amount of used space in RAM.	Bytes
system.disk.io.ops.per.sec	The number of read-write operations per second on the device.	Rate
uptime
uptime.sec	The time for which the system has been available.	Seconds
system.swap.memory.free.percent	The percentage of free swap space out of the total swap space.	Percentage
system.disk.io.bytes.per.sec	The amount of bytes transferred per second in I/O operations to and from the disk.	Rate
system.network.bytes.rate	The number of bytes sent/received for a device per second.	Rate
system.disk.io.queue.length	The queue length of IO requests issued to your device.	Count
system.memory.installed.bytes
system.cpu.percent	The percentage of a CPU being utilized at a particular instance.	Percentage
system.disk.free.bytes	The total amount of free disk space available on a system.	Bytes
system.memory.used.bytes	The total amount of used RAM on a system.	Bytes
system.memory.free.bytes	The total amount of free RAM space on a system.	Bytes
system.overall.memory.used.percent	The percentage of used RAM out of the total RAM.	Percentage
system.model	The model of the device.	String
system.running.processes	The total number of running processes in the system.	Count
system.cpu.user.percent	The percentage of time the CPU spent running user space processes.	Percentage
system.memory.free.percent	The percentage of free RAM out of total RAM.	Percentage
system.disk.free.percent	The percentage of free disk space out of the total disk space in the system.	Percentage
system.processor.queue.length	The number of threads that are delayed in the processor ready queue and are waiting to be executed.	Count
system.cpu.io.percent	The percentage of time the CPU spent waiting for IO operations to complete.	Percentage
system.disk.used.percent	The percentage of used disk space out of the total disk space on a system.	Percentage
system.network.error.packets	The total number of error packets in a network.	Count
system.threads	The total number of CPU threads.	Count
system.name	The name of the device.	String
system.disk.used.bytes	The total amount of used disk space on a system.	Count
system.network.out.bytes.rate
system.memory.used.percent	The percentage of used RAM out of total RAM.	Percentage
system.overall.memory.free.percent
system.cpu.kernel.percent	The percent of time the CPU spent running the kernel.	Percentage
system.cpu.idle.percent	The percentage of time the CPU has spent idle.	Percentage

CPU Core

Metrics	Description	Type
system.cpu.core	The number of CPU cores on the host.	Count
system.cpu.core.idle.percent	The percentage of time a particular CPU core has spent in idle state.	Percentage
system.cpu.core.percent	The percentage of a CPU core being utilized at a particular instance.	Percentage
system.cpu.core.user.percent	The percentage of time a given CPU core has spent in user mode	Percentage
system.cpu.core.kernel.percent	The percentage of time a given CPU core has spent in kernel mode	Percentage
system.cpu.core.io.percent	The percentage of time a given CPU core has spent waiting for I/O to complete	Percentage
system.cpu.core.interrupt.percent	The percentage of time a given CPU core has spent servicing the interrupts.	Percentage

Directory

Metrics	Description	Type
system.directory.files	The number of files in a directory	Count
system.directory.owner	The owner of the system directory	String
system.directory.mode.owner	The file access mode for a user who is an owner of particular directory.	String
system.directory.mode.group	The file access mode for a group that has access to a particular directory	String
system.directory	The name of the directory	String
system.directory.creation.time	The time at which the directory is created.	String
system.directory.modified.duration.minutes	The duration since the directory was last modified.	Seconds
system.directory.size.bytes	The size of the directory.	Bytes
status		String
system.directory.last.modified.time	The time at which the directory was last modifed by a user	String
system.directory.dirs		Count
system.directory.mode.others	The file access mode for all other users that are not owner of the directory.	String

Disk

Metrics	Description	Type
system.disk	The name of the particular disk.	String
system.disk.write.ops.per.sec	The writing operations performed on the disk per second.	Rate
system.disk.time.percent	The percentage of time spent doing I/O operations on the disk.	Count
system.disk.bytes.per.sec	The bytes transferred doing I/O operations to and from the disk per second.	Rate
system.disk.ops.per.sec	The I/O operations per second on the disk.	Count
system.disk.read.ops.per.sec	The reading operations per second to the disk.	Count
system.disk.read.bytes.per.sec	The bytes transferred per second reading from the disk.	Count
system.disk.write.bytes.per.sec	The bytes transferred per second writing to the disk.	Count
system.disk.queue.length	The queue length of IO requests issued to your device.	Count

File

Metrics	Description	Type
system.file.size.bytes	Total size of the file	Byte
system.file.last.modified.time	The time at which the file was last modified.	String
system.file.modified.duration.minutes	Duration since the file was last modified.	Minutes
system.file.mode.owner	The file access modes for the file if the permission group is ‘owner’.	String
system.file	The path and the file name of the file	String
system.file.creation.time	The time at which the file was created	String
system.file.owner	The user that created the file.	String
system.file.mode.group	The file access modes for the file if the permission group is ‘group’	String
system.file.mode.others	The file access modes for the file if the permission group is ‘others’	String
status	The status of the file whether it is available or not. The value is Up if the file is available and Down if the file is not available.	String

Network Interface

Metrics	Description	Type
system.network.interface	Name of the interface.	String
system.network.interface.in.bytes.rate	Bytes transferred per second to the network interface.	Rate
system.network.interface.out.bytes.rate	Bytes transferred per second out of the network interface.	Rate
system.network.interface.bytes.rate	Bytes transferred per second in or out of the network itnerface.	Rate

Process

Metrics	Description	Type
system.process.memory.used.percent	The percentage of RAM allocated for use by a process.	Count or percentage?
system.process.virtual.memory.bytes	The total amount of virtual memory used by a process.	Byte
system.process.handles	The number of handles used by a process.	Count
system.process.user	The name of the user that started the process.	String
system.process.cpu.percent	The CPU utilization of a process.	Percentage
system.process.uptime.sec	The total time in seconds for which the process is running.	Seconds
status	The status of the process. The value is Up if the process is available for monitoring and Down if the process is not available for monitoring.	String
system.process.memory.used.bytes	The total space used in a RAM by a process.	Byte
system.process.uptime	The total time for which the process is in runnning state.	String
system.process.threads	The number of threads used by this process.	Count
system.process.command	The command to identify the status of the process.	String
system.process.io.bytes.per.sec	The bytes transferred per second doing I/O operations to or from the disk for a process.	Rate
system.process	The name of the process.	String
system.process.id	The process Id.	Count
system.process.destination.port	The destination port to which the process communicates.	String
system.process	The name of the process.	String
system.process.source.ip	The source IP from which the process communicates.	String
system.process.destination.ip	The destination IP to which the process communicates.	String
system.process.source.port	The source port from which the process communicates.	String
