Ruckus Wireless
Overview
Ruckus Wireless, the reliable and high-performance wireless networking solution by Ruckus Networks, seamlessly integrates with Motadata AIOps to provide comprehensive monitoring and management capabilities. With this integration, organizations gain real-time visibility into the performance and health of their Ruckus wireless infrastructure. Monitor critical wireless network metrics such as client connections, signal strength, and access point utilization to ensure seamless and reliable wireless connectivity.
Prerequisites
- Before configuring the AIOps integration with Ruckus Wireless, ensure that you have the credentials for HTTP/HTTPS access to the Ruckus device.
List of Supported KPIs
| Metrics | Description | Type |
|---|---|---|
| ping.min.latency.ms | Minimum latency (in milliseconds) observed during ping | Count |
| ping.received.packets | Number of packets received during ping | Count |
| ping.lost.packets | Number of packets lost during ping | Count |
| ping.max.latency.ms | Maximum latency (in milliseconds) observed during ping | Count |
| object.target | Target object identifier | String |
| ping.sent.packets | Number of packets sent during ping | Count |
| ping.packet.lost.percent | Percentage of packet loss during ping | Percent |
| ping.latency.ms | Average latency (in milliseconds) observed during ping | Count |
| system.oid | System Object Identifier | String |
| started.time.sec | Uptime in Seconds for the monitor | Count |
| started.time | Uptime of the monitor | String |
| object.name | Name of the monitor | String |
| system.location | Location of the monitor | String |
| system.description | Description of the monitor | String |
| correlation.metrics | Correlation metrics between network connections | String |
| network.connection.tcp.connections | Number of TCP connections | Count |
| network.connection.udp.connections | Number of UDP connections | Count |
| network.connection.udp.error.segments | Number of UDP error segments | Count |
| network.connection.tcp.error.segments | Number of TCP error segments | Count |
| network.connection.tcp.retransmitted.segments | Number of TCP retransmitted segments | Count |
| destination.ip | Destination IP address | String |
| destination.port | Destination port number | Count |
| network.connection.protocol | Protocol used for network connection | Count |
| network.connection.state | State of the network connection | String |
| source.ip | Source IP address | String |
| source.port | Source port number | Count |
| interface.sent.discard.packets | Number of discarded packets sent on the interface | Count |
| interface.in.packets | Number of incoming packets on the interface | Count |
| interface.packets | Number of packets on the interface | Count |
| interface.error.packets | Number of error packets on the interface | Count |
| interface.sent.error.packets | Number of error packets sent on the interface | Count |
| interface.received.discard.packets | Number of discarded packets received on the interface | Count |
| interface.received.octets | Number of octets received on the interface | Count |
| interface.bit.type | Bit type of the interface | Count |
| status | Status of the interface | String |
| interface.out.packets | Number of outgoing packets on the interface | Count |
| interface.operational.status | Operational status of the interface | String |
| interface.admin.status | Admin status of the interface | Count |
| interface.sent.octets | Number of octets sent on the interface | Count |
| interface.last.change | Last change of the interface | String |
| interface.received.error.packets | Number of error packets received on the interface | Count |
| interface.discard.packets | Number of discarded packets on the interface | Count |
| started.time | Uptime of the interface | String |
| started.time.sec | Uptime in seconds of the interface | String |
| ruckus.wireless.active.wlans | Count of active WLANs | Count |
| ruckus.wireless.rogue.access.points | Count of rogue access points | Count |
| ruckus.wireless.licensed.access.points | Count of licensed access points | Count |
| ruckus.wireless.inactive.wlans | Count of inactive WLANs | Count |
| ruckus.wireless.wlans | Count of total wireless WLANs | Count |
| ruckus.wireless.access.points | Count of total wireless access points | Count |
| ruckus.wireless.access.point.reboots | Count of access point reboots | Count |
| ruckus.wireless.disconnected.access.points | Count of disconnected access points | Count |
| ruckus.wireless.healthy.clients | Count of healthy clients | Count |
| ruckus.wireless.excellent.clients | Count of excellent clients | Count |
| ruckus.wireless.clients | Count of total wireless clients | Count |
| ruckus.wireless.warning.clients | Count of warning clients | Count |
| ruckus.wireless.model | Model of the Ruckus wireless system | String |
| ruckus.wireless.system.name | Name of the Ruckus wireless system | String |
| ruckus.wireless.serial.no | Serial number of the Ruckus wireless system | String |
| ruckus.wireless.version | Version of the Ruckus wireless system | String |
| started.time | Uptime of the Ruckus wireless system (string) | String |
| started.time.sec | Uptime of the Ruckus wireless system (seconds) | Count |
| ruckus.wireless.access.point | Wireless Access Point | String |
| ruckus.wireless.access.point.cpu.percent | CPU Usage percentage of the Access Point | Count |
| ruckus.wireless.access.point.memory.installed.bytes | Installed Memory in Bytes of the Access Point | Count |
| ruckus.wireless.access.point.free.memory.bytes | Free Memory in Bytes of the Access Point | Count |
| ruckus.wireless.access.point.sent.bytes.rate | Rate of Bytes Sent by the Access Point | Count |
| ruckus.wireless.access.point.received.bytes.rate | Rate of Bytes Received by the Access Point | Count |
| ruckus.wireless.access.point.bytes.rate | Total Rate of Bytes (Sent + Received) | Count |
| ruckus.wireless.access.point.started.time.sec | Uptime of the Access Point in seconds | Count |
| ruckus.wireless.access.point.started.time | Uptime of the Access Point (string format) | String |
| ruckus.wireless.access.point.ip.type | Type of IP address (e.g., IPv4 or IPv6) | String |
| ruckus.wireless.access.point.description | Description of the Access Point | String |
| ruckus.wireless.access.point.location | Location of the Access Point | String |
| ruckus.wireless.access.point.external.ip | External IP address of the Access Point | String |
| ruckus.wireless.access.point.latitude | Latitude of the Access Point | String |
| ruckus.wireless.access.point.dns | DNS configuration of the Access Point | String |
| ruckus.wireless.access.point.netmask | Netmask configuration of the Access Point | String |
| ruckus.wireless.access.point.l3.connection.mode | L3 Connection Mode of the Access Point | String |
| ruckus.wireless.access.point.ip.address | Wireless Access Point IP Address | String |
| ruckus.wireless.access.point.ip6 | Ruckus Access Point IPv6 Address | String |
| ruckus.wireless.access.point.longitude | Ruckus Access Point Longitude | String |
| ruckus.wireless.access.point.mac.address | Wireless Access Point MAC Address | String |
| ruckus.wireless.access.point.model | Wireless Access Point Model | String |
| ruckus.wireless.access.point.tunnel.mode | Ruckus Access Point Tunnel Mode | String |
| ruckus.wireless.access.point.status | Wireless Access Point Status | String |
| ruckus.wireless.access.point.serial.number | Wireless Access Point Serial Number | String |
| ruckus.wireless.access.point.gateway | Ruckus Access Point Gateway | String |
| ruckus.wireless.access.point.external.port | Ruckus Access Point External Port | Count |
| ruckus.wireless.access.point.clients | Wireless Access Point Clients | Count |
| ruckus.wireless.access.point.vlan | Ruckus Access Point VLAN | Count |
| ruckus.wireless.access.point.version | Ruckus Access Point Version | String |
| ruckus.wireless.access.point.group | Wireless Access Point Group | String |
| ruckus.wireless.access.point.group | Represents the name of the wireless access point group in the Ruckus wireless system. | String |
| ruckus.wireless.access.point.group.description | Provides a brief description of the wireless access point group, detailing its purpose or attributes. | String |
| ruckus.wireless.access.point.group.id | A unique identifier assigned to the wireless access point group for internal tracking purposes. | Count |
| ruckus.wireless.access.point.group.access.points | Indicates the number of access points associated with the wireless access point group. | Count |
| interface | Refers to the network interface in the system, such as an Ethernet or Wi-Fi interface. | Count |
| interface.name | Specifies the name of the network interface for identification and reference. | String |
| interface.operational.status | Represents the current operational status of the network interface, such as 'up' or 'down'. | String |
| interface.speed.bytes.per.sec | Shows the data transfer speed of the network interface in bytes per second. | Count |
| interface.address | The IP address associated with the network interface. | String |
| interface.out.packets | The total number of outgoing packets transmitted through the network interface. | Count |
| interface.sent.octets | The total number of outgoing octets (bytes) transmitted through the network interface. | Count |
| interface.received.octets | The total number of incoming octets (bytes) received through the network interface. | Count |
| interface.in.packets | The total number of incoming packets received through the network interface. | Count |
| ruckus.wireless.wlan.name | The name of the Ruckus Wireless LAN (WLAN). | String |
| ruckus.wireless.wlan.description | A description providing additional information about the WLAN. | String |
| ruckus.wireless.wlan.authentication.type | The type of authentication used for client devices connecting to the WLAN. | String |
| ruckus.wireless.wlan.background.scanning | Indicates whether background scanning is enabled for the WLAN. | String |
| ruckus.wireless.wlan.group | The group to which the WLAN belongs. | String |
| ruckus.wireless.wlan | The name of the Ruckus Wireless LAN (WLAN). | String |
| ruckus.wireless.wlan.cipher | The cipher (encryption) algorithm used for securing WLAN communication. | String |
| ruckus.wireless.wlan.status | The current status of the WLAN, such as 'enabled' or 'disabled'. | String |
| ruckus.wireless.wlan.encryption | The type of encryption used for securing WLAN communication. | String |
| ruckus.wireless.wlan.clients | The number of client devices currently connected to the WLAN. | Count |
| ruckus.wireless.wlan.received.packets.rate | The rate at which packets are being received by the WLAN. | Count |
| ruckus.wireless.wlan.sent.packets.rate | The rate at which packets are being sent from the WLAN. | Count |
| ruckus.wireless.wlan.packets.rate | The overall rate of packet activity (both sent and received) on the WLAN. | Count |
| ruckus.wireless.wlan.traffic.received.bytes.rate | The rate at which data bytes are being received by the WLAN. | Count |
| ruckus.wireless.wlan.traffic.sent.bytes.rate | The rate at which data bytes are being sent from the WLAN. | Count |
| ruckus.wireless.wlan.traffic.bytes.rate | The overall rate of data bytes activity (both sent and received) on the WLAN. | Count |
| ruckus.wireless.wlan.access.vlan | The VLAN ID associated with client devices connecting to the WLAN. | Count |
| ruckus.wireless.wlan.id | The unique identifier for the Ruckus Wireless LAN (WLAN). | Count |
| ruckus.wireless.rogue.access.point | Represents a rogue access point detected in the wireless network. | String |
| ruckus.wireless.rogue.access.point.channel | The channel on which the rogue access point is operating. | Count |
| ruckus.wireless.rogue.type | Indicates the type or category of the detected rogue access point. | String |
| ruckus.wireless.rogue.access.point.last.detected | The date and time when the rogue access point was last detected. | String |
| ruckus.wireless.rogue.access.point.mac.address | The MAC address (unique identifier) of the rogue access point. | String |
| ruckus.wireless.rogue.access.point.encryption | The encryption method used by the rogue access point. | String |
| ruckus.wireless.rogue.access.point.interface.type | The type of interface used by the rogue access point (e.g., 802.11a/b/g/n/ac). | String |
| ruckus.wireless.rogue.access.point.status | The current status of the rogue access point, such as 'active' or 'inactive'. | String |
| ruckus.wireless.rogue.access.point.name | Name of the rogue access point | String |
| ruckus.wireless.client | Represents a wireless client connected to the Ruckus wireless network. | String |
| ruckus.wireless.client.os.type | The operating system type of the wireless client (if available, randomly generated otherwise). | String |
| ruckus.wireless.client.wlan.name | The name of the WLAN (Wireless Local Area Network) to which the client is connected. | String |
| ruckus.wireless.client.ap.mac.address | The MAC address (unique identifier) of the wireless access point the client is connected to. | String |
| ruckus.wireless.client.ap.ip.address | The IP address of the wireless access point the client is connected to. | String |
| ruckus.wireless.client.ipv6.address | The IPv6 address of the wireless client (if available). | String |
| ruckus.wireless.client.host.name | The host name of the wireless client (if available). | String |
| ruckus.wireless.client.auth.method | The authentication method used by the wireless client to connect to the network. | String |
| ruckus.wireless.client.auth.status | The authentication status of the wireless client (e.g., authenticated or not). | String |
| ruckus.wireless.client.status | The current status of the wireless client (e.g., online or offline). | String |
| ruckus.wireless.client.username | The username associated with the wireless client (if available). | String |
| ruckus.wireless.client.traffic.received.bytes.rate | The rate of incoming traffic in bytes per second for the wireless client. | Count |
| ruckus.wireless.client.traffic.sent.bytes.rate | The rate of outgoing traffic in bytes per second for the wireless client. | Count |
| ruckus.wireless.client.traffic.bytes.rate | The total rate of traffic (incoming + outgoing) in bytes per second for the wireless client. | Count |
| ruckus.wireless.client.channel | The channel frequency on which the wireless client is communicating. | Count |
| ruckus.wireless.client.vlan | The VLAN (Virtual Local Area Network) ID associated with the wireless client. | Count |
| ruckus.wireless.client.ip.address | The IPv4 address of the wireless client. | String |
| ruckus.wireless.client.inactive.time | The inactive time of the wireless client (if available, randomly generated otherwise). | String |
| ruckus.wireless.client.inactive.time.sec | The inactive time of the wireless client in seconds (if available, randomly generated otherwise). | Count |
| ruckus.wireless.client.wlan | The WLAN (Wireless Local Area Network) associated with the client (if available, randomly generated otherwise). | String |
| ruckus.wireless.client.uptime | The uptime of the wireless client (if available, randomly generated otherwise). | String |
| ruckus.wireless.client.health | The health status of the wireless client (if available, randomly generated otherwise). | String |
| ruckus.wireless.client.ap | The access point to which the wireless client is connected (if available, randomly generated otherwise). | String |
| ruckus.wireless.client.uptime.sec | The uptime of the wireless client in seconds (if available, randomly generated otherwise). | Count |
| ruckus.wireless.client.sent.packets.rate | The rate of sent packets by the wireless client (if available, randomly generated otherwise). | Count |
| ruckus.wireless.client.channelization | The channelization information of the wireless client (if available, randomly generated otherwise). | Count |
| ruckus.wireless.client.retries | The number of retries made by the wireless client (if available, randomly generated otherwise). | Count |
| ruckus.wireless.client.wlan.id | The WLAN ID associated with the wireless client (if available, randomly generated otherwise). | Count |
| ruckus.wireless.client.received.packets.rate | The rate of received packets by the wireless client (if available, randomly generated otherwise). | Count |
| ruckus.wireless.client.packets.rate | The rate of packets (sent + received) by the wireless client (if available, randomly generated otherwise). | Count |
| ruckus.wireless.client.snr | The signal-to-noise ratio (SNR) of the wireless client (if available, randomly generated otherwise). | Count |
| ruckus.wireless.client.signal.strength.dbm | The signal strength in dBm of the wireless client (if available, randomly generated otherwise). | Count |
