Bind 9
Overview
Bind 9, the widely used domain name system (DNS) software, seamlessly integrates with Motadata AIOps to provide comprehensive monitoring and management capabilities. With this integration, organizations gain real-time visibility into the performance and health of their DNS infrastructure. Monitor crucial DNS metrics such as query rates, response times, and zone transfer status to ensure efficient and reliable domain name resolution.
| Versions |
|---|
| 9 |
Prerequisites for BIND 9 Integration with Motadata AIOps
Ensure that the BIND 9 port (default: 8080) is open for the Motadata AIOps server.
Confirm that the BIND 9 process and service are listed in the process and monitor settings of Motadata AIOps. While these may be listed by default, ensure that the names of the service and process match the specific BIND 9 version that you intend to monitor.
Ensure that either HTTP or HTTPS are supported on the BIND 9 server.
Provide the necessary credentials, including the username and password, for Motadata AIOps to connect to the BIND 9 server.
Confirm that the BIND 9 service is active and running on the server.
For agentless monitoring, ensure that the user has the required access for remote access to the BIND 9 server. For agent-based monitoring, this is not required.
By following these prerequisites, you can integrate BIND 9 with Motadata AIOps and ensure the smooth functioning of the monitoring process.
List of Supported KPIs
Bind 9
| Name | Description | Type |
|---|---|---|
| system.tags | The system tags for the Bind9 metric. | String |
| bind9.version | The version of Bind9. | String |
| bind9.opcode.outgoing.requests.rate | The rate of outgoing requests for Bind9 opcode. | Count |
| bind9.opcode.incoming.requests.rate | The rate of incoming requests for Bind9 opcode. | Count |
| bind9.opcode.status.requests | The count of status requests for Bind9 opcode. | Count |
| bind9.opcode.reserved3.requests | The count of reserved3 requests for Bind9 opcode. | Count |
| bind9.opcode.notify.requests | The count of notify requests for Bind9 opcode. | Count |
| bind9.opcode.update.requests | The count of update requests for Bind9 opcode. | Count |
| bind9.opcode.reserved6.requests | The count of reserved6 requests for Bind9 opcode. | Count |
| bind9.opcode.reserved7.requests | The count of reserved7 requests for Bind9 opcode. | Count |
| bind9.opcode.reserved8.requests | The count of reserved8 requests for Bind9 opcode. | Count |
| bind9.opcode.reserved9.requests | The count of reserved9 requests for Bind9 opcode. | Count |
| bind9.opcode.reserved10.requests | The count of reserved10 requests for Bind9 opcode. | Count |
| bind9.opcode.reserved11.requests | The count of reserved11 requests for Bind9 opcode. | Count |
| bind9.opcode.reserved12.requests | The count of reserved12 requests for Bind9 opcode. | Count |
| bind9.opcode.reserved13.requests | The count of reserved13 requests for Bind9 opcode. | Count |
| bind9.opcode.reserved14.requests | The count of reserved14 requests for Bind9 opcode. | Count |
| bind9.opcode.reserved15.requests | The count of reserved15 requests for Bind9 opcode. | Count |
| bind9.zonestat.ipv4.sent.notifications | The count of sent IPv4 notifications for Bind9 zonestat. | Count |
| bind9.zonestat.ipv6.sent.notifications | The count of sent IPv6 notifications for Bind9 zonestat. | Count |
| bind9.zonestat.ipv4.received.notifications | The count of received IPv4 notifications for Bind9 zonestat. | Count |
| bind9.zonestat.ipv6.received.notifications | The count of received IPv6 notifications for Bind9 zonestat. | Count |
| bind9.zonestat.rejected.notifications | The count of rejected notifications for Bind9 zonestat. | Count |
| bind9.zonestat.sent.soa.ipv4.queries | The count of sent IPv4 SOA queries for Bind9 zonestat. | Count |
| bind9.zonestat.sent.soa.ipv6.queries | The count of sent IPv6 SOA queries for Bind9 zonestat. | Count |
| bind9.zonestat.ipv4.axfr.requests | The count of IPv4 AXFR requests for Bind9 zonestat. | Count |
| bind9.zonestat.ipv6.axfr.requests | The count of IPv6 AXFR requests for Bind9 zonestat. | Count |
| bind9.zonestat.ipv4.ixfr.requests | The count of IPv4 IXFR requests for Bind9 zonestat. | Count |
| bind9.zonestat.ipv6.ixfr.requests | The count of IPv6 IXFR requests for Bind9 zonestat. | Count |
| bind9.zonestat.successful.transfers | The count of successful transfers for Bind9 zonestat. | Count |
| bind9.zonestat.failed.transfers | The count of failed transfers for Bind9 zonestat. | Count |
| bind9.sockstat.udp4.opens | Number of UDPv4 sockets opened in Bind9 | Count |
| bind9.sockstat.udp6.opens | Number of UDPv6 sockets opened in Bind9 | Count |
| bind9.sockstat.tcp4.opens | Number of TCPv4 sockets opened in Bind9 | Count |
| bind9.sockstat.tcp6.opens | Number of TCPv6 sockets opened in Bind9 | Count |
| bind9.sockstat.unix.opens | Number of Unix sockets opened in Bind9 | Count |
| bind9.sockstat.raw.opens | Number of raw sockets opened in Bind9 | Count |
| bind9.sockstat.udp4.open.fails | Number of failed UDPv4 socket opens in Bind9 | Count |
| bind9.sockstat.udp6.open.fails | Number of failed UDPv6 socket opens in Bind9 | Count |
| bind9.sockstat.tcp4.open.fails | Number of failed TCPv4 socket opens in Bind9 | Count |
| bind9.sockstat.tcp6.open.fails | Number of failed TCPv6 socket opens in Bind9 | Count |
| bind9.sockstat.unix.failed.opens | Number of failed Unix socket opens in Bind9 | Count |
| bind9.sockstat.failed.sockets | Number of failed socket opens in Bind9 | Count |
| bind9.sockstat.udp4.closes | Number of UDPv4 sockets closed in Bind9 | Count |
| bind9.sockstat.udp6.closes | Number of UDPv6 sockets closed in Bind9 | Count |
| bind9.sockstat.tcp4.closes | Number of TCPv4 sockets closed in Bind9 | Count |
| bind9.sockstat.tcp6.closes | Number of TCPv6 sockets closed in Bind9 | Count |
| bind9.sockstat.unix.closes | Number of Unix sockets closed in Bind9 | Count |
| bind9.sockstat.fd.closes | Number of closed file descriptors in Bind9 | Count |
| bind9.sockstat.closed.raw.sockets | Number of closed raw sockets in Bind9 | Count |
| bind9.sockstat.udp4.bind.fails | Number of failed UDPv4 socket binds in Bind9 | Count |
| bind9.sockstat.udp6.bind.fails | Number of failed UDPv6 socket binds in Bind9 | Count |
| bind9.sockstat.tcp4.bind.fails | Number of failed TCPv4 socket binds in Bind9 | Count |
| bind9.sockstat.tcp6.bind.fails | Number of failed TCPv6 socket binds in Bind9 | Count |
| bind9.sockstat.unix.bind.fails | Number of failed Unix socket binds in Bind9 | Count |
| bind9.sockstat.bind.fd.fails | Number of failed file descriptor binds in Bind9 | Count |
| bind9.sockstat.udp4.failed.connects | Number of failed UDPv4 socket connects in Bind9 | Count |
| bind9.sockstat.udp6.failed.connects | Number of failed UDPv6 socket connects in Bind9 | Count |
| bind9.sockstat.tcp4.connection.fails | Number of failed TCPv4 connections in Bind9 | Count |
| bind9.sockstat.tcp6.connections.fails | Number of failed TCPv6 connections in Bind9 | Count |
| bind9.sockstat.unix.failed.connects | Number of failed Unix socket connects in Bind9 | Count |
| bind9.sockstat.failed.fd.connections | Number of failed file descriptor connections in Bind9 | Count |
| bind9.sockstat.udp4.connections.rate | Rate of UDPv4 connections in Bind9 | Count |
| bind9.sockstat.udp6.connections.rate | Rate of UDPv6 connections in Bind9 | Count |
| bind9.sockstat.tcp4.connections.rate | Rate of TCPv4 connections in Bind9 | Count |
| bind9.sockstat.successful.tcp6.connections | Number of successful TCPv6 connections in Bind9 | Count |
| bind9.sockstat.unix.connects | Number of Unix socket connections in Bind9 | Count |
| bind9.sockstat.successful.fd.connections | Number of successful file descriptor connections in Bind9 | Count |
| bind9.sockstat.tcp4.accept.fails | Number of failed TCPv4 accepts in Bind9 | Count |
| bind9.sockstat.tcp6.accept.fails | Number of failed TCPv6 accepts in Bind9 | Count |
| bind9.sockstat.unix.connection.failed.accepts | Number of failed Unix connection accepts in Bind9 | Count |
| bind9.sockstat.tcp4.accepted.connections | Number of accepted TCPv4 connections in Bind9 | Count |
| bind9.sockstat.tcp6.accepts | Number of TCPv6 accepts in Bind9 | Count |
| bind9.sockstat.unix.connection.accepts | Number of Unix connection accepts in Bind9 | Count |
| bind9.sockstat.udp4.send.errors | Number of UDPv4 send errors in Bind9 | Count |
| bind9.sockstat.udp6.send.errors | Number of UDPv6 send errors in Bind9 | Count |
| bind9.sockstat.tcp4.send.errors | Number of TCPv4 send errors in Bind9 | Count |
| bind9.sockstat.tcp6.send.errors | Number of TCPv6 send errors in Bind9 | Count |
| bind9.sockstat.unix.send.errors | Number of Unix send errors in Bind9 | Count |
| bind9.sockstat.sent.errors | Number of sent errors in Bind9 | Count |
| bind9.sockstat.udp4.receive.errors | Number of UDPv4 receive errors in Bind9 | Count |
| bind9.sockstat.udp6.receive.errors | Number of UDPv6 receive errors in Bind9 | Count |
| bind9.sockstat.tcp4.receive.errors | Number of TCPv4 receive errors in Bind9 | Count |
| bind9.sockstat.tcp6.receive.errors | Number of TCPv6 receive errors in Bind9 | Count |
| bind9.sockstat.unix.receive.errors | Number of Unix receive errors in Bind9 | Count |
| bind9.sockstat.received.fd.errors | Number of received file descriptor errors in Bind9 | Count |
| bind9.sockstat.received.errors | Number of received errors in Bind9 | Count |
| bind9.sockstat.udp4.active.connections | Number of active UDPv4 connections in Bind9 | Count |
| bind9.sockstat.udp6.active.connections | Number of active UDPv6 connections in Bind9 | Count |
| bind9.sockstat.tcp4.active.connections | Number of active TCPv4 connections in Bind9 | Count |
| bind9.sockstat.tcp6.active.connections | Number of active TCPv6 connections in Bind9 | Count |
| bind9.sockstat.unix.active.connections | Number of active Unix connections in Bind9 | Count |
| bind9.sockstat.raw.active.connections | Number of active raw connections in Bind9 | Count |
| bind9.nsstat.ipv4.requests | Number of IPv4 requests in Bind9 | Count |
| bind9.nsstat.ipv6.requests | Number of IPv6 requests in Bind9 | Count |
| bind9.nsstat.received.edns0.requests | Number of received EDNS0 requests in Bind9 | Count |
| bind9.nsstat.bad.edns.requests | Number of bad EDNS requests in Bind9 | Count |
| bind9.nsstat.tsig.requests | Number of TSIG requests in Bind9 | Count |
| bind9.nsstat.received.tsig0.requests | Number of received TSIG0 requests in Bind9 | Count |
| bind9.nsstat.bad.tsig.requests | Number of bad TSIG requests in Bind9 | Count |
| bind9.nsstat.tcp.requests.rate | Rate of TCP requests in Bind9 | Count |
| bind9.nsstat.rejected.auth.queries | Number of rejected authoritative queries in Bind9 | Count |
| bind9.nsstat.rejected.recursive.queries | Number of rejected recursive queries in Bind9 | Count |
| bind9.nsstat.rejected.zone.transfers | Number of rejected zone transfers in Bind9 | Count |
| bind9.nsstat.rejected.updates | Number of rejected updates in Bind9 | Count |
| bind9.nsstat.sent.responses | Number of sent responses in Bind9 | Count |
| bind9.nsstat.sent.truncated.responses | Number of sent truncated responses in Bind9 | Count |
| bind9.nsstat.sent.edns0.responses | Number of sent EDNS0 responses in Bind9 | Count |
| bind9.nsstat.sent.tsig.responses | Number of sent TSIG responses in Bind9 | Count |
| bind9.nsstat.sent.tsig0.responses | Number of sent TSIG0 responses in Bind9 | Count |
| bind9.nsstat.successful.queries | Number of successful queries in Bind9 | Count |
| bind9.nsstat.answered.auth.queries | Number of answered authoritative queries in Bind9 | Count |
| bind9.nsstat.noanswered.auth.queries | Number of no answered authoritative queries in Bind9 | Count |
| bind9.nsstat.referral.answered.queries | Number of answered referral queries in Bind9 | Count |
| bind9.nsstat.empty.queries | Number of empty queries in Bind9 | Count |
| bind9.nsstat.failed.served.queries | Number of failed served queries in Bind9 | Count |
| bind9.nsstat.former.queries | Number of former queries in Bind9 | Count |
| bind9.nsstat.domain.nx.queries | Number of domain NX queries in Bind9 | Count |
| bind9.nsstat.recursive.queries | Number of recursive queries in Bind9 | Count |
| bind9.nsstat.duplicate.queries | Number of duplicate queries in Bind9 | Count |
| bind9.nsstat.dropped.queries | Number of dropped queries in Bind9 | Count |
| bind9.nsstat.failed.queries | Number of failed queries in Bind9 | Count |
| bind9.nsstat.completed.zone.transfers | Number of completed zone transfers in Bind9 | Count |
| bind9.nsstat.request.forward.updates | Number of forward update requests in Bind9 | Count |
| bind9.nsstat.forward.response.updates | Number of forward response updates in Bind9 | Count |
| bind9.nsstat.forward.failed.updates | Number of failed forward updates in Bind9 | Count |
| Bind9 Nsstat Updates | Number of updates made by Bind9 | Count |
| Bind9 Nsstat Failed Updates | Number of failed updates in Bind9 | Count |
| Bind9 Nsstat Bad Prerequisite Updates | Number of updates with bad prerequisites in Bind9 | Count |
| Bind9 Nsstat Recursive Clients | Number of recursive clients in Bind9 | Count |
| Bind9 Nsstat Dns64 | Number of Dns64 operations in Bind9 | Count |
| Bind9 Nsstat Rate Drops | Rate of dropped queries in Bind9 | Count |
| Bind9 Nsstat Rate Slips | Rate of slipped queries in Bind9 | Count |
| Bind9 Nsstat Policy Zone Rewrite Responses | Number of responses for policy zone rewriting in Bind9 | Count |
| Bind9 Nsstat Udp Queries Rate | Rate of UDP queries in Bind9 | Count |
| Bind9 Nsstat Tcp Queries Rate | Rate of TCP queries in Bind9 | Count |
| Bind9 Nsstat Nsid Options | Number of NSID options used in Bind9 | Count |
| Bind9 Nsstat Expired Options | Number of expired options in Bind9 | Count |
| Bind9 Nsstat Other Options | Number of other options in Bind9 | Count |
| Bind9 Nsstat Sit Bad Size | Number of SIT queries with bad size in Bind9 | Count |
| Bind9 Nsstat Sit Bad Time | Number of SIT queries with bad time in Bind9 | Count |
| Bind9 Nsstat Sit Matches | Number of SIT queries that matched in Bind9 | Count |
| Bind9 Nsstat Sit New Requests | Number of new SIT queries made in Bind9 | Count |
| Bind9 Nsstat Sit Nomatches | Number of SIT queries with no matches in Bind9 | Count |
| Bind9 Nsstat Sit Options | Number of SIT queries with options in Bind9 | Count |
| Bind9 Nsstat Redirect Nx Queries | Number of redirected NX queries in Bind9 | Count |
| Bind9 Nsstat Redirect Rlookup Nx Queries | Number of redirected reverse lookup NX queries in Bind9 | Count |
