Cisco Wireless

Overview

Cisco Wireless, the industry-leading wireless networking solution by Cisco Systems, seamlessly integrates with Motadata AIOps to provide comprehensive monitoring and management capabilities. With this integration, organizations gain real-time visibility into the performance and health of their Cisco wireless infrastructure. Monitor critical wireless network metrics such as client connections, signal strength, and access point utilization to ensure seamless and reliable wireless connectivity.

Prerequisites

• Ensure that the Cisco device is SNMP enabled before configuring the AIOps integration.

List of Supported KPIs

Metrics	Description	Type
ping.min.latency.ms	Minimum latency (in milliseconds) observed during ping	Count
ping.received.packets	Number of packets received during ping	Count
ping.lost.packets	Number of packets lost during ping	Count
ping.max.latency.ms	Maximum latency (in milliseconds) observed during ping	Count
object.target	Target object identifier	String
ping.sent.packets	Number of packets sent during ping	Count
ping.packet.lost.percent	Percentage of packet loss during ping	Percent
ping.latency.ms	Average latency (in milliseconds) observed during ping	Count
system.oid	System Object Identifier	String
started.time.sec	Uptime in Seconds for the monitor	Count
started.time	Uptime of the monitor	String
object.name	Name of the monitor	String
system.location	Location of the monitor	String
system.description	Description of the monitor	String
correlation.metrics	Correlation metrics between network connections	String
network.connection.tcp.connections	Number of TCP connections	Count
network.connection.udp.connections	Number of UDP connections	Count
network.connection.udp.error.segments	Number of UDP error segments	Count
network.connection.tcp.error.segments	Number of TCP error segments	Count
network.connection.tcp.retransmitted.segments	Number of TCP retransmitted segments	Count
destination.ip	Destination IP address	String
destination.port	Destination port number	Count
network.connection.protocol	Protocol used for network connection	Count
network.connection.state	State of the network connection	String
source.ip	Source IP address	String
source.port	Source port number	Count
interface.sent.discard.packets	Number of discarded packets sent on the interface	Count
interface.in.packets	Number of incoming packets on the interface	Count
interface.packets	Number of packets on the interface	Count
interface.error.packets	Number of error packets on the interface	Count
interface.sent.error.packets	Number of error packets sent on the interface	Count
interface.received.discard.packets	Number of discarded packets received on the interface	Count
interface.received.octets	Number of octets received on the interface	Count
interface.bit.type	Bit type of the interface	Count
status	Status of the interface	String
interface.out.packets	Number of outgoing packets on the interface	Count
interface.operational.status	Operational status of the interface	String
interface.admin.status	Admin status of the interface	Count
interface.sent.octets	Number of octets sent on the interface	Count
interface.last.change	Last change of the interface	String
interface.received.error.packets	Number of error packets received on the interface	Count
interface.discard.packets	Number of discarded packets on the interface	Count
started.time	Uptime of the interface	String
started.time.sec	Uptime in seconds of the interface	String
cisco.wireless.access.point.interface.power.level	Power level of the Cisco access point interface	Count
cisco.wireless.access.point.interface.operational.status	Operational status of the Cisco access point interface	String
cisco.wireless.access.point.interface.admin.status	Administrative status of the Cisco access point interface	String
cisco.wireless.access.point.interface.current.channel	Current channel of the wireless access point interface	String
cisco.wireless.access.point.interface.type	Type of the wireless access point interface	String
cisco.wireless.access.point.interface.wlan.override	WLAN override setting of the Cisco access point interface	String
cisco.wireless.access.point.interface	Identifier of the wireless access point interface	String
cisco.wireless.access.point.location	Location of the wireless access point	String
cisco.wireless.access.point.started.time.sec	Uptime of the wireless access point in seconds	Count
status	Status of the wireless access point	String
cisco.wireless.access.point	Identifier of the wireless access point	String
cisco.wireless.access.point.mac.address	MAC address of the wireless access point	String
cisco.wireless.access.point.slots	Number of slots in the wireless access point	Count
cisco.wireless.access.point.group	Group associated with the wireless access point	String
cisco.wireless.access.point.serial.number	Serial number of the wireless access point	String
cisco.wireless.access.point.admin.status	Administrative status of the Cisco access point	String
cisco.wireless.access.point.operational.status	Operational status of the Cisco access point	String
cisco.wireless.access.point.ip.address	IP address of the wireless access point	String
cisco.wireless.access.point.model	Model of the wireless access point	String
cisco.wireless.access.point.clients	Number of clients connected to the wireless access point	Count
cisco.wireless.wlans	Number of wireless WLANs configured in the Cisco wireless network	Count
cisco.wireless.controller.memory.used.percent	Memory usage percentage of the Cisco wireless controller	Count
cisco.wireless.version	Version of the Cisco wireless controller	String
cisco.wireless.controller.ip.address	IP address of the Cisco wireless controller	String
cisco.wireless.controller.cpu.temperature.celsius	CPU temperature of the Cisco wireless controller in Celsius	Count
cisco.wireless.controller.802.11b.network.state	State of the 802.11b network in the Cisco wireless controller	String
cisco.wireless.controller.cpu.percent	CPU usage percentage of the Cisco wireless controller	Count
started.time	Start time of the Cisco wireless controller	String
cisco.wireless.clients	Number of clients connected to the Cisco wireless controller	Count
cisco.wireless.controller.802.11a.network.state	State of the 802.11a network in the Cisco wireless controller	String
cisco.wireless.controller.memory.free.bytes	Free memory in bytes of the Cisco wireless controller	Count
started.time.sec	Uptime of the Cisco wireless controller in seconds	Count
cisco.wireless.controller.memory.used.bytes	Used memory in bytes of the Cisco wireless controller	Count
cisco.wireless.access.points	Number of wireless access points in the Cisco wireless network	Count
cisco.wireless.controller.mac.address	MAC address of the wireless controller	String
cisco.wireless.controller.product.code	Product code of the wireless controller	String
cisco.wireless.controller.product.name	Product name of the wireless controller	String
cisco.wireless.controller.serial.number	Serial number of the wireless controller	String
cisco.wireless.controller.manufacturer.name	Manufacturer name of the wireless controller	String
cisco.wireless.wlan	Name of the wireless WLAN	String
cisco.wireless.wlan.status	Status of the wireless WLAN	String
cisco.wireless.wlan.id	ID of the wireless WLAN	Count
cisco.wireless.wlan.interface.name	Interface name of the Cisco WLAN	String
cisco.wireless.rogue.access.points	Number of wireless rogue access points	Count
cisco.wireless.rogue.clients	Number of wireless rogue clients	Count
cisco.wireless.rogue.access.point.name	Name of the Cisco rogue access point	String
cisco.wireless.rogue.access.point.channel	Channel of the wireless rogue access point	String
cisco.wireless.rogue.access.point.last.detected	Last detected time of the wireless rogue access point	String
cisco.wireless.rogue.access.point.class.type	Class type of the wireless rogue access point	String
cisco.wireless.rogue.type	Type of the wireless rogue	String
cisco.wireless.rogue.access.point.state	State of the Cisco rogue access point	String
cisco.wireless.rogue.access.point.mac.address	MAC address of the wireless rogue access point	String
cisco.wireless.rogue.access.point.clients	Number of clients associated with the Cisco rogue AP	String
cisco.wireless.rogue.client.ssid	SSID of the wireless rogue client	String
cisco.wireless.rogue.client	Name of the Cisco rogue client	String
cisco.wireless.rogue.client.ap.mac.address	MAC address of the Cisco rogue client's AP	String
cisco.wireless.rogue.client.state	State of the Cisco rogue client	String
cisco.wireless.rogue.client.last.detected	Last detected time of the Cisco rogue client	String
cisco.wireless.client	Cisco wireless client	String
cisco.wireless.client.protocol	Cisco wireless client protocol	String
cisco.wireless.client.ap	Wireless client access point	String
cisco.wireless.client.snr	Signal-to-Noise Ratio (SNR) of the wireless client	Count
cisco.wireless.client.association.mode	Cisco wireless client association mode	String
cisco.wireless.client.os.type	Operating system type of the wireless client	String
cisco.wireless.client.wlan	WLAN (Wireless Local Area Network) of the client	String
cisco.wireless.client.channel	Channel of the wireless client	String
cisco.wireless.client.traffic.received.bytes.rate	Traffic received bytes rate of the wireless client	Count
cisco.wireless.client.signal.strength.dbm	Signal strength in dBm of the wireless client	Count
cisco.wireless.client.traffic.sent.bytes.rate	Traffic sent bytes rate of the wireless client	Count
cisco.wireless.client.packets.rate	Packets rate of the wireless client	Count
cisco.wireless.client.interface.type	Interface type of the wireless client	String
cisco.wireless.client.ip.address	IP address of the wireless client	String
cisco.wireless.client.ap.mac.address	MAC address of the access point connected by the client	String
cisco.wireless.client.traffic.bytes.rate	Traffic bytes rate of the wireless client	Count
cisco.wireless.client.ap.ip.address	IP address of the access point connected by the client	String
cisco.wireless.client.status	Status of the wireless client	String
cisco.wireless.client.username	Username of the wireless client	String
cisco.wireless.client.started.time.sec	Uptime of the wireless client in seconds	Count
cisco.wireless.client.received.packets.rate	Received packets rate of the wireless client	Count
cisco.wireless.client.sent.packets.rate	Sent packets rate of the wireless client	Count
cisco.wireless.client.auth.method	Authentication method of the wireless client	String
