Active Directory
Overview
Active Directory, the powerful and centralized identity management service developed by Microsoft, seamlessly integrates with Motadata AIOps to provide comprehensive monitoring capabilities. With this integration, organizations gain real-time visibility into the performance and health of their Active Directory infrastructure. Monitor critical directory service metrics such as user authentication rates, group membership changes, and domain controller status to ensure efficient and secure user access.
Supported Versions
| Versions |
|---|
| Windows Server 2012 |
Prerequisites for Microsoft Active Directory Integration with Motadata AIOps
Obtain the server credentials required for discovering the server on which Microsoft Active Directory is installed.
Ensure that the user has administrator privileges on the server where Microsoft Active Directory is installed.
Ensure that the Microsoft Active Directory service is active and running on the server.
Confirm that the Microsoft Active Directory process and service are listed in the process and service monitor settings of Motadata AIOps. While these may be listed by default, verify that the names of the service and process match the specific Microsoft Active Directory version that you intend to monitor.
By meeting these prerequisites, you can integrate Microsoft Active Directory with Motadata AIOps and enable effective monitoring and management of your Microsoft Active Directory server.
List of Supported KPIs
Active Directory
| Name | Description | Type |
|---|---|---|
| ad.address.book.searches.per.sec | The number of address book searches per second. | Count |
| ad.dns.root | The DNS root associated with Active Directory. | String |
| ad.forest | The forest name of Active Directory. | String |
| ad.ldap.searches.per.sec | The number of LDAP searches per second. | Count |
| ad.ldap.bind.time.ms | The time taken for LDAP bind operation in milliseconds. | Count |
| ad.sam.password.changes.per.sec | The number of SAM password changes per second. | Count |
| ad.ldap.client.sessions | The number of LDAP client sessions. | Count |
| ad.orphan.objects | The number of orphan objects in Active Directory. | Count |
| ad.ds.notify.queue.size | The size of the Directory Service (DS) notify queue in Active Directory. | Count |
| ad.address.book.client.sessions | The number of address book client sessions. | Count |
| ad.dra.pending.replication.synchronizations | The number of pending replication synchronizations in Active Directory. | Count |
| ad.dra.inbound.bytes.per.sec | The rate of inbound bytes per second for Active Directory replication. | Count |
| ad.dra.outbound.bytes.per.sec | The rate of outbound bytes per second for Active Directory replication. | Count |
| ad.dra.inbound.objects.per.sec | The rate of inbound objects per second in Active Directory replication. | Count |
| ad.ldra.outbound.objects.per.sec | The rate of outbound objects per second in Active Directory replication. | Count |
| ad.dra.sync.requests | The number of synchronization requests in Active Directory replication. | Count |
| ad.dra.inbound.full.sync.pending.objects | The number of inbound full sync pending objects in Active Directory replication. | Count |
| ad.dra.inbound.dns.values.per.sec | The rate of inbound DNS values per second in Active Directory replication. | Count |
| ad.dra.outbound.dns.values.per.sec | The rate of outbound DNS values per second in Active Directory replication. | Count |
| ad.ldap.successful.binds.per.sec | The number of successful LDAP binds per second. | Count |
| ad.ldap.active.threads | The number of active threads in LDAP operations. | Count |
| ad.ds.active.threads | The number of active threads in Active Directory directory service operations. | Count |
| ad.ds.directory.reads.per.sec | The rate of directory reads per second in Active Directory. | Count |
| ad.ds.directory.writes.per.sec | The rate of directory writes per second in Active Directory. | Count |
| ad.sam.successful.user.creations.per.sec | The number of successful user creations per second in Active Directory Security Account Manager (SAM). | Count |
| ad.sam.membership.changes.per.sec | The number of membership changes per second in Active Directory Security Account Manager (SAM). | Count |
| ad.sam.user.creation.attempts.per.sec | The number of user creation attempts per second in Active Directory Security Account Manager (SAM). | Count |
| ad.ldap.new.connections.per.sec | The rate of new LDAP connections per second in Active Directory. | Count |
| ad.ds.server.binds.per.sec | The rate of server binds per second in Active Directory. | Count |
| ad.ds.client.binds.per.sec | The rate of client binds per second in Active Directory. | Count |
| ad.ds.directory.searches.per.sec | The rate of directory searches per second in Active Directory. | Count |
| ad.kdc.requests | The number of KDC (Key Distribution Center) requests in Active Directory. | Count |
| ad.kerberos.authentications.per.sec | The rate of Kerberos authentications per second in Active Directory. | Count |
| ad.ntlm.authentications.per.sec | The rate of NTLM (NT LAN Manager) authentications per second in Active Directory. | Count |
| ad.kdc.tgs.requests.per.sec | The rate of TGS (Ticket Granting Service) requests per second in Active Directory. | Count |
| ad.atq.outstanding.queued.requests | The number of outstanding queued requests in Active Directory ATQ (Asynchronous Thread Queue). | Count |
| ad.atq.request.latency.ms | The latency of ATQ (Asynchronous Thread Queue) requests in Active Directory, measured in ms. | Count |
| ad.atq.estimated.queue.delay.ms | The estimated delay in the ATQ (Asynchronous Thread Queue) queue in Active Directory, measured in ms. | Count |
| ad.atq.ldap.threads | The number of LDAP threads in Active Directory ATQ (Asynchronous Thread Queue). | Count |
| ad.database.cache.hit.ratio.percent | The percentage of cache hits in the Active Directory database cache. | Count |
| ad.database.reads.average.latency.ms | The average latency of database reads in Active Directory, measured in milliseconds. | Count |
| ad.database.reads.per.sec | The rate of database reads per second in Active Directory. | Count |
| ad.log.record.stalls.per.sec | The rate of log record stalls per second in Active Directory. | Count |
| ad.log.write.average.latency.ms | The average latency of log writes in Active Directory, measured in milliseconds. | Count |
| ad.log.writes.per.sec | The rate of log writes per second in Active Directory. | Count |
| ad.database.cache.size.bytes | The size of the database cache in Active Directory, measured in bytes. | Count |
| ad.log.waiting.threads | The number of threads waiting for log operations in Active Directory. | Count |
| ad.table.open.cache.hit.ratio.percent | The percentage of cache hits in the table open cache in Active Directory. | Count |
| ad.database.page.faults.per.sec | The rate of database page faults per second in Active Directory. | Count |
| ad.database.page.fault.stalls.per.sec | The rate of stalls caused by database page faults per second in Active Directory. | Count |
| ad.table.opens.per.sec | The rate of table opens per second in Active Directory. | Count |
| ad.log.file | The log file in Active Directory. | Count |
| ad.log.file.size.bytes | The size of the log file in Active Directory, measured in bytes. | Count |
Active Directory Replication
| Name | Description | Type |
|---|---|---|
| ad.replication | Represents the general status of Active Directory replication. | String |
| ad.replication.destination | The destination of Active Directory replication. | String |
| ad.replication.site | The site of Active Directory replication. | String |
| ad.replication.domain.name | The domain name of Active Directory replication. | String |
| ad.replication.naming.context | The naming context of Active Directory replication. | String |
| ad.replication.status | The status of Active Directory replication. | String |
| ad.replication.last.attempted | The timestamp of the last attempted replication. | String |
| ad.replication.error.code | The error code associated with Active Directory replication. | String |
| ad.replication.error.message | The error message associated with Active Directory replication. | String |
| ad.replication.protocol | The protocol used for Active Directory replication. | String |
Active Directory Role
| Name | Description | Type |
|---|---|---|
| ad.role.forest | The forest of the Active Directory role. | String |
| ad.role.status | The status of the Active Directory role. | String |
| ad.role | The Active Directory role. | String |
| ad.role.domain | The domain of the Active Directory role. | String |
