Aruba Wireless

Overview

Aruba Wireless, the advanced and reliable wireless networking solution by Aruba Networks, seamlessly integrates with Motadata AIOps to provide comprehensive monitoring and management capabilities. With this integration, organizations gain real-time visibility into the performance and health of their Aruba wireless infrastructure. Monitor critical wireless network metrics such as client connections, signal strength, and access point utilization to ensure seamless and reliable wireless connectivity.

Prerequisites

• Ensure that the Aruba device is SNMP enabled before configuring the AIOps integration.

List of Supported KPIs

Metrics	Description	Type
ping.min.latency.ms	Minimum latency (in milliseconds) observed during ping	Count
ping.received.packets	Number of packets received during ping	Count
ping.lost.packets	Number of packets lost during ping	Count
ping.max.latency.ms	Maximum latency (in milliseconds) observed during ping	Count
object.target	Target object identifier	String
ping.sent.packets	Number of packets sent during ping	Count
ping.packet.lost.percent	Percentage of packet loss during ping	Percent
ping.latency.ms	Average latency (in milliseconds) observed during ping	Count
system.oid	System Object Identifier	String
started.time.sec	Uptime in Seconds for the monitor	Count
started.time	Uptime of the monitor	String
object.name	Name of the monitor	String
system.location	Location of the monitor	String
system.description	Description of the monitor	String
correlation.metrics	Correlation metrics between network connections	String
network.connection.tcp.connections	Number of TCP connections	Count
network.connection.udp.connections	Number of UDP connections	Count
network.connection.udp.error.segments	Number of UDP error segments	Count
network.connection.tcp.error.segments	Number of TCP error segments	Count
network.connection.tcp.retransmitted.segments	Number of TCP retransmitted segments	Count
destination.ip	Destination IP address	String
destination.port	Destination port number	Count
network.connection.protocol	Protocol used for network connection	Count
network.connection.state	State of the network connection	String
source.ip	Source IP address	String
source.port	Source port number	Count
interface.sent.discard.packets	Number of discarded packets sent on the interface	Count
interface.in.packets	Number of incoming packets on the interface	Count
interface.packets	Number of packets on the interface	Count
interface.error.packets	Number of error packets on the interface	Count
interface.sent.error.packets	Number of error packets sent on the interface	Count
interface.received.discard.packets	Number of discarded packets received on the interface	Count
interface.received.octets	Number of octets received on the interface	Count
interface.bit.type	Bit type of the interface	Count
status	Status of the interface	String
interface.out.packets	Number of outgoing packets on the interface	Count
interface.operational.status	Operational status of the interface	String
interface.admin.status	Admin status of the interface	Count
interface.sent.octets	Number of octets sent on the interface	Count
interface.last.change	Last change of the interface	String
interface.received.error.packets	Number of error packets received on the interface	Count
interface.discard.packets	Number of discarded packets on the interface	Count
started.time	Uptime of the interface	String
started.time.sec	Uptime in seconds of the interface	String
aruba.wireless.access.point.interface.clients	Number of clients connected to the wireless access point	Count
aruba.wireless.access.point.interface.received.bytes.rate	Rate of received bytes on the wireless access point interface	Count
aruba.wireless.access.point.interface.ssid	SSID (Service Set Identifier) of the wireless access point	String
aruba.wireless.access.point.interface.mac.address	MAC address of the wireless access point interface	String
aruba.wireless.access.point.interface.packets.rate	Rate of packets on the wireless access point interface	Count
aruba.wireless.access.point.interface.sent.bytes.rate	Rate of sent bytes on the wireless access point interface	Count
aruba.wireless.access.point.interface.current.channel	Current channel of the wireless access point interface	String
aruba.wireless.access.point.interface.type	Type of the wireless access point interface	String
aruba.wireless.access.point.interface	Interface of the wireless access point	String
aruba.wireless.access.point.interface.received.packets.rate	Rate of received packets on the wireless access point interface	Count
aruba.wireless.access.point.interface.sent.packets.rate	Rate of sent packets on the wireless access point interface	Count
aruba.wireless.access.point.interface.bytes.rate	Rate of bytes on the wireless access point interface	Count
aruba.wireless.access.point.started.time	Uptime of the wireless access point	String
aruba.wireless.access.point.started.time.sec	Uptime in seconds of the wireless access point	Count
aruba.wireless.access.point.mac.address	MAC address of the wireless access point	String
aruba.wireless.access.point.clients	Number of clients associated with the wireless access point	String
aruba.wireless.access.point	Wireless access point	String
aruba.wireless.access.point.location	Location of the wireless access point	String
aruba.wireless.access.point.status	Status of the wireless access point	String
aruba.wireless.access.point.model	Model of the wireless access point	Count
aruba.wireless.access.point.group	Group to which the wireless access point belongs	String
aruba.wireless.access.point.ip.address	IP address of the wireless access point	String
aruba.wireless.access.point.slots	Slots available on the wireless access point	String
aruba.wireless.access.point.serial.number	Serial number of the wireless access point	Count
aruba.wireless.controller.memory.installed.bytes	Installed memory size of the wireless controller	Count
aruba.wireless.controller.memory.used.bytes	Memory usage of the wireless controller	Count
aruba.wireless.controller.cpu.percent	CPU utilization percentage of the wireless controller	Count
aruba.wireless.version	Version of the wireless software	Count
aruba.wireless.controller.temperature.celsius	Temperature of the wireless controller in Celsius	Count
aruba.wireless.controller.ip.address	IP address of the wireless controller	String
started.time	Uptime of the wireless system	String
aruba.wireless.controller.memory.used.percent	Memory usage percentage of the wireless controller	Count
aruba.wireless.controller.memory.free.bytes	Free memory available on the wireless controller	Count
aruba.wireless.access.points	Number of access points associated with the controller	Count
aruba.wireless.controller.mac.address	MAC address of the wireless controller	String
aruba.wireless.wlans	Number of WLANs configured on the wireless controller	Count
aruba.wireless.clients	Number of clients connected to the wireless network	Count
started.time.sec	Uptime in seconds of the wireless system	Count
aruba.wireless.controller.serial.number	Serial number of the wireless controller	String
aruba.wireless.controller.model.name	Model name of the wireless controller	String
aruba.wireless.controller.host.name	Host name of the wireless controller	String
aruba.wireless.wlan.traffic.received.bytes.per.sec	Rate of received traffic in bytes per second on the WLAN	Count
aruba.wireless.wlan.down.access.points	Number of access points with the WLAN in a down state	Count
aruba.wireless.wlan.up.access.points	Number of access points with the WLAN in an up state	Count
aruba.wireless.wlan.bytes.per.sec	Rate of data transfer in bytes per second on the WLAN	Count
aruba.wireless.wlan.received.packets.rate	Rate of received packets on the WLAN	Count
aruba.wireless.wlan	WLAN name	String
aruba.wireless.wlan.packets.rate	Rate of packets on the WLAN	Count
aruba.wireless.wlan.sent.packets.rate	Rate of sent packets on the WLAN	Count
aruba.wireless.wlan.traffic.sent.bytes.per.sec	Rate of sent traffic in bytes per second on the WLAN	Count
aruba.wireless.wlan.access.points	Number of access points associated with the WLAN	Count
aruba.wireless.wlan.clients	Number of clients connected to the WLAN	Count
aruba.wireless.rogue.access.point.status	Status of the rogue access point	String
aruba.wireless.rogue.access.point.channel	Channel of the rogue access point	Count
aruba.wireless.rogue.access.point.ssid	SSID (Service Set Identifier) of the rogue access point	String
aruba.wireless.rogue.access.point	Rogue access point identifier	String
aruba.wireless.rogue.access.point.class.type	Class type of the rogue access point	String
aruba.wireless.rogue.access.point.interface.type	Interface type of the rogue access point	String
aruba.wireless.rogue.client.class.type	Class type of the rogue client	String
aruba.wireless.rogue.client.ssid	SSID (Service Set Identifier) of the rogue client	String
aruba.wireless.rogue.client	Rogue client identifier	String
aruba.wireless.rogue.client.ap.bssid	BSSID (Basic Service Set Identifier) of the rogue client	String
aruba.wireless.rogue.client.channel	Channel of the rogue client	Count
aruba.wireless.rogue.client.interface.type	Interface type of the rogue client	String
aruba.wireless.rogue.client.status	Status of the rogue client	String
aruba.wireless.rogue.access.points	Number of rogue access points detected	Count
aruba.wireless.rogue.clients	Number of rogue clients detected	Count
aruba.wireless.client.auth.method	Authentication method used by the wireless client	String
aruba.wireless.client.received.packets.rate	Rate of received packets by the wireless client	Count
aruba.wireless.client.packets.rate	Rate of packets transmitted by the wireless client	Count
aruba.wireless.client.ap.mac.address	MAC address of the access point associated with the client	String
aruba.wireless.client.username	Username of the wireless client	String
aruba.wireless.client.started.time.sec	Uptime of the wireless client in seconds	Count
aruba.wireless.client.sent.packets.rate	Rate of packets sent by the wireless client	Count
aruba.wireless.client.traffic.bytes.rate	Rate of traffic (bytes) exchanged by the wireless client	Count
aruba.wireless.client.ap	Access point identifier of the wireless client	String
aruba.wireless.client.ip.address	IP address of the wireless client	String
aruba.wireless.client	Identifier of the wireless client	String
aruba.wireless.client.interface.type	Interface type of the wireless client	String
aruba.wireless.client.channel	Channel used by the wireless client	String
aruba.wireless.client.wlan	WLAN (Wireless Local Area Network) associated with the client	String
aruba.wireless.client.status	Status of the wireless client	String
aruba.wireless.client.os.type	Operating system type of the wireless client	String
aruba.wireless.client.ap.bss.id	BSSID (Basic Service Set Identifier) of the access point	String
aruba.wireless.client.started.time	Uptime of the wireless client	Count
aruba.wireless.client.traffic.received.bytes.rate	Rate of received traffic (bytes) by the wireless client	Count
aruba.wireless.client.traffic.sent.bytes.rate	Rate of sent traffic (bytes) by the wireless client	Count
aruba.wireless.client.signal.strength.dbm	Signal strength of the wireless client in dBm	Count
aruba.wireless.client.ap.ip.address	IP address of the access point associated with the client	String
