Ubuntu
Overview
The Ubuntu integration in Motadata AIOps empowers users to monitor and optimize their Ubuntu-based systems effectively. By collecting and analyzing performance metrics, log data, and system information from Ubuntu servers and devices, this integration offers valuable insights into the health and performance of the Ubuntu infrastructure. With real-time visibility, administrators can proactively address potential issues, fine-tune resource utilization, and ensure the seamless functioning of their Ubuntu environment, enhancing overall operational efficiency and reliability.
Prerequisites
Kindly refer the prerequisites for Adding Linux Servers for Monitoring here.
List of Supported KPIs
Ubuntu
| Metrics | Description | Type |
|---|---|---|
| system.network.in.bytes.rate | Rate | |
| system.overall.memory.free.bytes | The amount of free space available in RAM on your host. | Bytes |
| system.load.avg15.min | The average system load over fifteen minutes. (available for Linux only) | Percentage |
| system.cpu.type | ||
| system.swap.memory.free.bytes | The amount of free swap space. | Bytes |
| system.swap.memory.used.percent | The percentage of used swap memory in your system. | Percentage |
| system.vendor | The name of the vendor for the monitoring device | String |
| system.load.avg1.min | The average system load over one minute. (available for Linux only) | Percentage |
| system.network.udp.connections | The total number of UDP connections. | Count |
| system.load.avg5.min | The average system load over five minutes. (available for Linux only) | Percentage |
| system.blocked.processes | The number of blocked processes in the system. | Count |
| system.opened.file.descriptors | The number of file descriptors used by a particular process. | Count |
| system.cache.memory.bytes | The amount of the RAM used as cache memory. | Bytes |
| system.swap.memory.provisioned.bytes | Bytes | |
| system.disk.io.time.percent | The percentage of time spent reading or writing to the disk | Percentage |
| system.network.tcp.connections | The total number of TCP connections. | Count |
| system.virtual | ||
| system.cpu.cores | The number of CPU cores on your host. | Count |
| system.os.name | The name of the operating system on your host. | String |
| system.os.version | The version of the operating system on your host. | String |
| system.context.switches.per.sec | The number of context switches per second. | Rate |
| system.disk.capacity.bytes | The capacity of the disk. | Bytes |
| system.network.tcp.retransmissions | The count of lost or damaged packets that were resent over the network. | Count |
| system.buffer.memory.bytes | The amount of the RAM used as buffer memory. | Bytes |
| system.swap.memory.used.bytes | The amount of used swap space in your system. | Bytes |
| system.cpu.interrupt.percent | The percentage of time the CPU has spent servicing hardware interrupts | |
| system.memory.available.bytes | The amount of free RAM. | Bytes |
| system.interrupts.per.sec | The number of CPU interrupts per second. | Rate |
| system.overall.memory.used.bytes | The amount of used space in RAM. | Bytes |
| system.disk.io.ops.per.sec | The number of read-write operations per second on the device. | Rate |
| uptime | ||
| uptime.sec | The time for which the system has been available. | Seconds |
| system.swap.memory.free.percent | The percentage of free swap space out of the total swap space. | Percentage |
| system.disk.io.bytes.per.sec | The amount of bytes transferred per second in I/O operations to and from the disk. | Rate |
| system.network.bytes.rate | The number of bytes sent/received for a device per second. | Rate |
| system.disk.io.queue.length | The queue length of IO requests issued to your device. | Count |
| system.memory.installed.bytes | ||
| system.cpu.percent | The percentage of a CPU being utilized at a particular instance. | Percentage |
| system.disk.free.bytes | The total amount of free disk space available on a system. | Bytes |
| system.memory.used.bytes | The total amount of used RAM on a system. | Bytes |
| system.memory.free.bytes | The total amount of free RAM space on a system. | Bytes |
| system.overall.memory.used.percent | The percentage of used RAM out of the total RAM. | Percentage |
| system.model | The model of the device. | String |
| system.running.processes | The total number of running processes in the system. | Count |
| system.cpu.user.percent | The percentage of time the CPU spent running user space processes. | Percentage |
| system.memory.free.percent | The percentage of free RAM out of total RAM. | Percentage |
| system.disk.free.percent | The percentage of free disk space out of the total disk space in the system. | Percentage |
| system.processor.queue.length | The number of threads that are delayed in the processor ready queue and are waiting to be executed. | Count |
| system.cpu.io.percent | The percentage of time the CPU spent waiting for IO operations to complete. | Percentage |
| system.disk.used.percent | The percentage of used disk space out of the total disk space on a system. | Percentage |
| system.network.error.packets | The total number of error packets in a network. | Count |
| system.threads | The total number of CPU threads. | Count |
| system.name | The name of the device. | String |
| system.disk.used.bytes | The total amount of used disk space on a system. | Count |
| system.network.out.bytes.rate | ||
| system.memory.used.percent | The percentage of used RAM out of total RAM. | Percentage |
| system.overall.memory.free.percent | ||
| system.cpu.kernel.percent | The percent of time the CPU spent running the kernel. | Percentage |
| system.cpu.idle.percent | The percentage of time the CPU has spent idle. | Percentage |
CPU Core
| Metrics | Description | Type |
|---|---|---|
| system.cpu.core | The number of CPU cores on the host. | Count |
| system.cpu.core.idle.percent | The percentage of time a particular CPU core has spent in idle state. | Percentage |
| system.cpu.core.percent | The percentage of a CPU core being utilized at a particular instance. | Percentage |
| system.cpu.core.user.percent | The percentage of time a given CPU core has spent in user mode | Percentage |
| system.cpu.core.kernel.percent | The percentage of time a given CPU core has spent in kernel mode | Percentage |
| system.cpu.core.io.percent | The percentage of time a given CPU core has spent waiting for I/O to complete | Percentage |
| system.cpu.core.interrupt.percent | The percentage of time a given CPU core has spent servicing the interrupts. | Percentage |
Directory
| Metrics | Description | Type |
|---|---|---|
| system.directory.files | The number of files in a directory | Count |
| system.directory.owner | The owner of the system directory | String |
| system.directory.mode.owner | The file access mode for a user who is an owner of particular directory. | String |
| system.directory.mode.group | The file access mode for a group that has access to a particular directory | String |
| system.directory | The name of the directory | String |
| system.directory.creation.time | The time at which the directory is created. | String |
| system.directory.modified.duration.minutes | The duration since the directory was last modified. | Seconds |
| system.directory.size.bytes | The size of the directory. | Bytes |
| status | String | |
| system.directory.last.modified.time | The time at which the directory was last modifed by a user | String |
| system.directory.dirs | Count | |
| system.directory.mode.others | The file access mode for all other users that are not owner of the directory. | String |
Disk
| Metrics | Description | Type |
|---|---|---|
| system.disk | The name of the particular disk. | String |
| system.disk.write.ops.per.sec | The writing operations performed on the disk per second. | Rate |
| system.disk.time.percent | The percentage of time spent doing I/O operations on the disk. | Count |
| system.disk.bytes.per.sec | The bytes transferred doing I/O operations to and from the disk per second. | Rate |
| system.disk.ops.per.sec | The I/O operations per second on the disk. | Count |
| system.disk.read.ops.per.sec | The reading operations per second to the disk. | Count |
| system.disk.read.bytes.per.sec | The bytes transferred per second reading from the disk. | Count |
| system.disk.write.bytes.per.sec | The bytes transferred per second writing to the disk. | Count |
| system.disk.queue.length | The queue length of IO requests issued to your device. | Count |
File
| Metrics | Description | Type |
|---|---|---|
| system.file.size.bytes | Total size of the file | Byte |
| system.file.last.modified.time | The time at which the file was last modified. | String |
| system.file.modified.duration.minutes | Duration since the file was last modified. | Minutes |
| system.file.mode.owner | The file access modes for the file if the permission group is ‘owner’. | String |
| system.file | The path and the file name of the file | String |
| system.file.creation.time | The time at which the file was created | String |
| system.file.owner | The user that created the file. | String |
| system.file.mode.group | The file access modes for the file if the permission group is ‘group’ | String |
| system.file.mode.others | The file access modes for the file if the permission group is ‘others’ | String |
| status | The status of the file whether it is available or not. The value is Up if the file is available and Down if the file is not available. | String |
Network Interface
| Metrics | Description | Type |
|---|---|---|
| system.network.interface | Name of the interface. | String |
| system.network.interface.in.bytes.rate | Bytes transferred per second to the network interface. | Rate |
| system.network.interface.out.bytes.rate | Bytes transferred per second out of the network interface. | Rate |
| system.network.interface.bytes.rate | Bytes transferred per second in or out of the network itnerface. | Rate |
Process
| Metrics | Description | Type |
|---|---|---|
| system.process.memory.used.percent | The percentage of RAM allocated for use by a process. | Count or percentage? |
| system.process.virtual.memory.bytes | The total amount of virtual memory used by a process. | Byte |
| system.process.handles | The number of handles used by a process. | Count |
| system.process.user | The name of the user that started the process. | String |
| system.process.cpu.percent | The CPU utilization of a process. | Percentage |
| system.process.uptime.sec | The total time in seconds for which the process is running. | Seconds |
| status | The status of the process. The value is Up if the process is available for monitoring and Down if the process is not available for monitoring. | String |
| system.process.memory.used.bytes | The total space used in a RAM by a process. | Byte |
| system.process.uptime | The total time for which the process is in runnning state. | String |
| system.process.threads | The number of threads used by this process. | Count |
| system.process.command | The command to identify the status of the process. | String |
| system.process.io.bytes.per.sec | The bytes transferred per second doing I/O operations to or from the disk for a process. | Rate |
| system.process | The name of the process. | String |
| system.process.id | The process Id. | Count |
| system.process.destination.port | The destination port to which the process communicates. | String |
| system.process | The name of the process. | String |
| system.process.source.ip | The source IP from which the process communicates. | String |
| system.process.destination.ip | The destination IP to which the process communicates. | String |
| system.process.source.port | The source port from which the process communicates. | String |
