Tomcat
- version: 4.4
- Compatibility: v 7.5.900 and v 7.6.0
- Requires: Host/IP/CIDR/CSV (Mandatory), Port (Mandatory), JMX Port (Mandatory), Usename (Mandatory), Password (Mandatory), Metric Collect Interval (Mandatory)
- Operation: monitors the Tomcat.
- Plugin-Metrics:
- version: 4.3
- Compatibility: v 7.5.3
- Requires: Host/IP/CIDR/CSV (Mandatory), Port (Mandatory), JMX Port (Mandatory), Usename (Mandatory), Password (Mandatory), Metric Collect Interval (Mandatory)
- Operation: monitors the Tomcat.
- Plugin-Metrics:
Tomcat
| Metric | Data Type |
|---|---|
| Threads | Numeric |
| Busy Threads | Numeric |
| Max Threads | Numeric |
| Connections | Numeric |
| Used Heap Memory (MB) | Numeric |
| Heap Memory (%) | Numeric |
| Used Non Heap Memory (MB) | Numeric |
| Non Heap Memory (%) | Numeric |
| JSP Accesses | Numeric |
| JSP Reloads | Numeric |
| JSP Unloads | Numeric |
| Uptime | String |
| System Uptime (Seconds) | Numeric |
| Active Sessions | Numeric |
| Expired Sessions | Numeric |
| Rejected Sessions | Numeric |
| Created Sessions | Numeric |
| Sessions/sec | Numeric |
| Sent Bytes | Numeric |
| Received Bytes | Numeric |
| Errors | Numeric |
| Max Request Time (ms) | Numeric |
| Request Time (ms) | Numeric |
| Requests | Numeric |
| Sent Bytes/sec | Numeric |
| Received Bytes/sec | Numeric |
| Bytes | Numeric |
| Bytes/sec | Numeric |
| Requests/sec | Numeric |
| Cache Hits | Numeric |
| Cache Accesses | Numeric |
| Cache Hit Ratio (%) | Numeric |
| Version | String |
Instance Columns:
Thread Pool
| Metric | Data Type |
|---|---|
| Thread Pool | String |
| Thread Pool Threads | Numeric |
| Thread Pool Busy Threads | Numeric |
| Thread Pool Max Threads | Numeric |
| Thread Pool Connections | Numeric |
JDBC Pool
| Metric | Data Type |
|---|---|
| JDBC Pool | String |
| JDBC Pool Active Connections | Numeric |
| JDBC Pool Idle Connections | Numeric |
