Active Directory
- version: 7.9
- Compatibility: v 7.6.2
- Requires: Host/IP/CIDR/CSV (Mandatory), Port (Mandatory), Username (Mandatory), Password (Mandatory), Metric Collection Interval (Mandatory)
- Operation: Collects information from active directory.
- Change from Last Plugin: Bug fix: Addition of Flag for Duplication with values YES or NO. Default: NO
- Plugin-Metrics:
- version: 7.8
- Compatibility: v 7.5.7
- Requires: Host/IP/CIDR/CSV (Mandatory), Port (Mandatory), Username (Mandatory), Password (Mandatory), Metric Collection Interval (Mandatory)
- Operation: Collects information from active directory.
- Change from Last Plugin: Bug fix: Not polling data in some cases
- Plugin-Metrics:
Active Directory
| Metric | Data Type |
|---|---|
| System Uptime (Seconds): | Numeric |
| Uptime: | String |
| LDAP Searches/sec: | Numeric |
| LDAP Bind Time (ms): | Numeric |
| SAM Password Changes/sec: | Numeric |
| LDAP Client Sessions: | Numeric |
| DS Notify Queue Size: | Numeric |
| Address Book Client Sessions: | Numeric |
| DRA Pending Replication Synchronizations: | Numeric |
| DRA Inbound Bytes/sec: | Numeric |
| DRA Outbound Bytes/sec: | Numeric |
| DRA Inbound Objects/sec: | Numeric |
| DRA Outbound Objects/sec: | Numeric |
| DRA Sync Requests: | Numeric |
| DRA Inbound Full Sync Pending Objects: | Numeric |
| DRA Inbound Values (Dns only)/sec: | Numeric |
| DRA Outbound Values (Dns only)/sec: | Numeric |
| LDAP Successful Binds: | Numeric |
| LDAP Active Threads: | Numeric |
| DS Active Threads: | Numeric |
| DS Directory Reads/sec: | Numeric |
| DS Directory Writes/sec: | Numeric |
| SAM User Creations/sec: | Numeric |
| SAM Membership Changes/sec: | Numeric |
| SAM User Creation Attempts/sec: | Numeric |
| LDAP New Connections/sec: | Numeric |
| DS Server Binds/sec: | Numeric |
| Address Book Searches/sec: | Numeric |
| DS Client Binds/sec: | Numeric |
| DS Directory Searches/sec: | Numeric |
| KDC Requests: | Numeric |
| Kerberos Authentications/sec: | Numeric |
| NTLM Authentications/sec: | Numeric |
| KDC TGS Requests/sec: | Numeric |
| ATQ Outstanding Queued Requests: | Numeric |
| ATQ Request Latency (ms): | Numeric |
| ATQ Estimated Queue Delay (ms): | Numeric |
| ATQ LDAP Threads: | Numeric |
| Database Cache Hit Ratio (%): | Numeric |
| Database I/O Read Latency (ms): | Numeric |
| Database I/O Reads/sec: | Numeric |
| Database Log Record Stalls/sec: | Numeric |
| Database Log Write Latency (ms): | Numeric |
| Database Log Writes/sec: | Numeric |
| Database Cache Size (Bytes): | Numeric |
| Database Log Waiting Threads: | Numeric |
| Database Table Open Cache Hit Ratio (%): | Numeric |
| Database Page Faults/sec: | Numeric |
| Database Page Fault Stalls/sec: | Numeric |
| Database Table Opens/sec: | Numeric |
- Instance Metrics
| Metric | Data Type |
|---|---|
| Service | String |
| Service Name | String |
| Service Status | String |
| Log File | String |
| Log File Size (kb) | Numeric |
- Data Models
primary: “Active Directory Metrics†instance:
- name: “Active Directory Log File Metrics†columns: “Log File,Log File Size (KB)â€
- name: “Active Directory Service Metrics†columns: “Service,Service Name,Service Statusâ€
Active Directory
- version: 7.6
- Compatibility: v 7.5.3
- Requires: Host/IP/CIDR/CSV (Mandatory), Port (Mandatory), Username (Mandatory), Password (Mandatory), Metric Collection Interval (Mandatory)
- Operation: Collects information from active directory.
