Nutanix Cluster
- version: 1.0
- Compatibility: v 7.5.500
- Requires: Host/IP/CIDR/CSV (Mandatory), Port (Mandatory), SSL Enabled (Mandatory), Username (Optional), Password (Optional), Metric Collection Interval (Mandatory)
- Operation: Collects information from switch devices.
Nutanix Cluster Metrics
- Plugin-Metrics:
| Metric | Data Type |
|---|---|
| Cluster UUID | String |
| Number of Hosts | Numeric |
| Number of VMs | Numeric |
| Cluster Name | String |
| Cluster IP | String |
| Timezone | String |
| AOS Version | String |
| Hypervisor | String |
| Storage Reserved Free (MB) | Numeric |
| Storage Reserved Used (MB) | Numeric |
| Storage Reserved Capacity (MB) | Numeric |
| Storage Tier SSD Free (MB) | Numeric |
| Storage Tier SSD Used (MB) | Numeric |
| Storage Tier SSD Capacity (MB) | Numeric |
| Storage Tier SATA Free (MB) | Numeric |
| Storage Tier SATA Used (MB) | Numeric |
| Storage Tier SATA Capacity (MB) | Numeric |
| Free Storage (MB) | Numeric |
| Used Storage (MB) | Numeric |
| Total Storage (MB) | Numeric |
| Memory Usage (MB) | Numeric |
| Write IOPS | Numeric |
| Read IOPS | Numeric |
| IOPS | Numeric |
| Average IO Latency | Numeric |
| IO Bandwidth kBps | Numeric |
| Controller Write IOPS | Numeric |
| Controller Read IOPS | Numeric |
| Controller IOPS | Numeric |
| Controller Average IO Latency | Numeric |
| Controller IO Bandwidth kBps | Numeric |
| Hypervisor Write IOPS | Numeric |
| Hypervisor Read IOPS | Numeric |
| Hypervisor IOPS | Numeric |
| Hypervisor Average IO Latency | Numeric |
| Hypervisor IO Bandwidth kBps | Numeric |
| Hypervisor CPU Usage (%) | Numeric |
| Hypervisor Hyper-V CPU Usage (%) | Numeric |
| Hypervisor KVM CPU Usage (%) | Numeric |
| Hypervisor ESX CPU Usage (%) | Numeric |
| Hypervisor Memory Usage (%) | Numeric |
| Hypervisor Hyper-V Memory Usage (%) | Numeric |
| Hypervisor KVM Memory Usage (%) | Numeric |
| Hypervisor ESX Memory Usage (%) | Numeric |
| Dead VM | Numeric |
| Bully VM | Numeric |
| Over Provisioned VM | Numeric |
| Inefficient VM | Numeric |
| Constrained VM | Numeric |
| Power On VMs | Numeric |
| Power Off VMs | Numeric |
| Number of Storage Containers | Numeric |
| Number of Disks | Numeric |
| Read IO Bandwidth (kBps) | Numeric |
| Write IO Bandwidth (kBps) | Numeric |
| Total Cluster Unresolved Alerts | Numeric |
Instance Columns:
Host
| Metric | Data Type |
|---|---|
| Host | String |
| Host Name | String |
| Host State | String |
| Host Type | String |
| Host CVM IP | String |
| Host OpLog Disk Size | Numeric |
| Host OpLog Disk (%) | Numeric |
| Host IP | String |
| Host VMs | String |
| Host Hypervisor | String |
| Host Memory (MB) | String |
VM
| Metric | Data Type |
|---|---|
| VM | String |
| VM Name | String |
| VM Host Name | String |
| VM Description | String |
| VM Guest OS | String |
| VM Memory (MB) | Numeric |
| VM IP Addresses | String |
| VM VCPUs | Numeric |
| VM Power State | String |
Storage Container
| Metric | Data Type |
|---|---|
| Storage Container | String |
| Storage Container Name | String |
| Storage Container Capacity (Bytes) | Numeric |
| Storage Container Free (Bytes) | Numeric |
| Storage Container Used (Bytes) | Numeric |
| Storage Container Free (%) | Numeric |
| Storage Container Used (%) | Numeric |
| Storage Container Controller Write IOPS | Numeric |
| Storage Container Controller Read IOPS | Numeric |
| Storage Container Controller IOPS | Numeric |
| Storage Container Controller Average IO Latency (usecs) | Numeric |
| Storage Container Controller IO Bandwidth kBps | Numeric |
Disk
| Metric |
|---|
