Windows
- Version: 8.5
- Compatibility: v 7.7.903
- Requires: Host/IP/CIDR/CSV (Mandatory), Port (Mandatory), Username (Mandatory), Password (Mandatory), Metric Collect Interval (Mandatory), Processes (Optional), Services (Optional), Service Start Mode (Mandatory)
- Operation: Monitors the Windows systems
- Version: 8.4
- Compatibility: v 7.7.9
- Requires: Host/IP/CIDR/CSV (Mandatory), Port (Mandatory), Username (Mandatory), Password (Mandatory), Metric Collect Interval (Mandatory), Processes (Optional), Services (Optional), Service Start Mode (Mandatory)
- Operation: Monitors the Windows systems
- version: 8.3
- Compatibility: v 7.7.7
- Requires: Host/IP/CIDR/CSV (Mandatory), Port (Mandatory), Username (Mandatory), Password (Mandatory), Metric Collect Interval (Mandatory), Processes (Optional), Services (Optional), Service Start Mode (Mandatory)
- Operation: Monitors the Windows systems
- Changes from last version: Improvement: Support for IPv6 addresses is added.
- version: 8.2
- Compatibility: v 7.7.0
- Requires: Host/IP/CIDR/CSV (Mandatory), Port (Mandatory), Username (Mandatory), Password (Mandatory), Metric Collect Interval (Mandatory), Processes (Optional), Services (Optional), Service Start Mode (Mandatory)
- Operation: Monitors the Windows
- Changes from last version: Packet Loss KPI is visible in GUI
- Plugin-Metrics:
Windows
- version: 8.1
- Compatibility: v 7.6.8
- Requires: Host/IP/CIDR/CSV (Mandatory), Port (Mandatory), Username (Mandatory), Password (Mandatory), Metric Collect Interval (Mandatory), Processes (Optional), Services (Optional), Service Start Mode (Mandatory)
- Operation: monitors the Windows
- Changes from last version: Monitoring of Net Adapter Speed added
- Plugin-Metrics:
Windows
- version: 7.9
- Compatibility: v 7.6.2
- Requires: Host/IP/CIDR/CSV (Mandatory), Port (Mandatory), Username (Mandatory), Password (Mandatory), Metric Collect Interval (Mandatory), Processes (Optional), Services (Optional), Service Start Mode (Mandatory)
- Operation: monitors the Windows
- Changes from last version: Addition of Flag for Duplication with values YES or NO. Default: NO
- Plugin-Metrics:
Windows
- version: 7.5
- Compatibility: v 7.5.3
- Requires: Host/IP/CIDR/CSV (Mandatory), Port (Mandatory), Username (Mandatory), Password (Mandatory), Metric Collect Interval (Mandatory), Processes (Optional), Services (Optional), Service Start Mode (Mandatory)
- Operation: monitors the Windows.
- Plugin-Metrics:
Windows
| Metric | Data Type |
|---|---|
| CPU (%) | Numeric |
| Memory (%) | Numeric |
| RTT (ms) | Numeric |
| Disk (%) | Numeric |
| Interrupts/sec | Numeric |
| User CPU (%) | Numeric |
| Interrupt CPU (%) | Numeric |
| Free Memory (MB) | Numeric |
| Idle CPU(%) | Numeric |
| Cache Memory (MB) | Numeric |
| Available Memory (MB) | Numeric |
| Paged Memory (MB) | Numeric |
| Non Paged Memory (MB) | Numeric |
| Committed Memory (MB) | Numeric |
| Committed Memory Limit (MB) | Numeric |
| Pages/sec | Numeric |
| Page Faults/sec | Numeric |
| Context Switches/sec | Numeric |
| Disk Capacity (MB) | Numeric |
| Free Disk (MB) | Numeric |
| Used Disk (MB) | Numeric |
| Network IN Traffic (bps) | Numeric |
| Network OUT Traffic (bps) | Numeric |
| Network Traffic (bps) | Numeric |
| Network Output Queue Length | Numeric |
| Uptime (Seconds) | Numeric |
| Uptime | String |
| System Name | String |
| System Fan Status | String |
| Physical Processors | Numeric |
| Power State | String |
| Power Consumption | Numeric |
| Vendor | String |
| Model | String |
| CPU Type | String |
| Installed Memory (MB) | Numeric |
| Used Memory (MB) | Numeric |
| OS Name | String |
| OS Version | String |
| OS Service Pack | String |
| CPU Description | String |
| CPU Cores | Numeric |
| Temperature | Numeric |
| Logical Processors | Numeric |
| Running Processes | Numeric |
| Processor Queue Length | Numeric |
| Threads | Numeric |
| Serial Number | String |
| instance-columns |
Disk Volume
| Metric | Data Type |
|---|---|
| Disk Volume | String |
| Disk Volume Capacity (MB) | Numeric |
| Disk Volume Free (MB) | Numeric |
| Disk Volume Used (MB) | Numeric |
| Disk Volume Utilization (%) | Numeric |
Disk
| Disk | String |
|---|---|
| Disk Byte Reads/sec | Numeric |
| Disk Byte Writes/sec | Numeric |
| Disk Writes/sec | Numeric |
| Disk Reads/sec | Numeric |
| Disk Read Time (%) | Numeric |
| Disk Write Time (%) | Numeric |
| Disk I/O Time (%) | Numeric |
| Disk Queue Length | Numeric |
| Disk Bytes/sec | Numeric |
| Disk I/O Ops/sec | Numeric |
Service
| Metric | Data Type |
|---|---|
| Service | String |
| Service Name | String |
| Service Status | String |
| Service Start Mode | String |
Interface
| Metric | Data Type |
|---|---|
| Interface | String |
| Interface IN Traffic (bps) | Numeric |
| Interface OUT Traffic (bps) | Numeric |
| Interface Traffic (bps) | Numeric |
Process
| Metric | Data Type |
|---|
