JVM

  • version: 3.2
  • Compatibility: v 7.5.3
  • Requires: Host/IP/CIDR/CSV (Mandatory), JMX Port (Mandatory), User Name (Optional), Password (Optional), Metric Collect Interval (Second)
  • Operation: Collects information from JVM devices.
  • Plugin-Metrics:

JVM

JVM

MetricData Type
Class Path:String
Library Path:String
Vendor:String
Version:String
System Uptime (Seconds):Numeric
VM Name:String
VM Version:String
VM Args:String
Uptime:String
CPU (%):Numeric
Heap Memory (MB):Numeric
Non Heap Memory (MB):Numeric
Pending Finalization Objects:Numeric
Committed Heap Memory (MB):Numeric
Init Heap Memory (MB):Numeric
Used Heap Memory (MB):Numeric
Heap Memory (%):Numeric
Committed Non Heap Memory (MB):Numeric
Init Non Heap Memory (MB):Numeric
Used Non Heap Memory (MB):Numeric
Collections:Numeric
Collection Time (Seconds):Numeric
Loaded Classes:Numeric
Unloaded Classes:Numeric
Compilation Time (Seconds):Numeric
Threads:Numeric

Instance:

MetricData Type
Committed Memory PoolNumeric
Init Memory PoolNumeric
Max Memory PoolNumeric
Used Memory PoolNumeric
Memory PoolString
Memory Pool UtilizationNumeric

Data Models

primary: “JVM Metrics”

instance:

  • name: “JVM Memory Pool Metrics” columns: “Committed Memory Pool (MB),Init Memory Pool (MB),Max Memory Pool (MB),Used Memory Pool (MB),Memory Pool,Memory Pool Utilization (%)”
