Exchange 2016 Mailbox and Client Access Role

• version: 1.1
• Compatibility: v 7.7.1
• Requires: Host/IP/CIDR/CSV (Mandatory), Port (Mandatory), Username (Mandatory), Password (Mandatory), Metric Collector Time (Mandatory)
• Operation: Sends and receives emails.
• Change from last version: Bug Fix: Timeout Issue resolved

Exchange 2016 Mailbox and Client Access Role

---

• version: 1.0
• Compatibility: v 7.6.6
• Requires: Host/IP/CIDR/CSV (Mandatory), Port (Mandatory), Username (Mandatory), Password (Mandatory), Metric Collector Time (Mandatory)
• Operation: Sends and receives emails.
• Plugin-Metrics:

Exchange 2016 Mailbox and Client Access Role

Metric	Data Type
RPC Client Connections:	Numeric
Uptime:	String
RPC Operations/sec:	Numeric
RPC Active Users:	Numeric
RPC Requests:	Numeric
RPC Latency (ms):	Numeric
RPC Users:	Numeric
Ping Pending Commands:	Numeric
Sync Pending Commands:	Numeric
Sync Active Requests:	Numeric
Availability Requests:	Numeric
Availability Free/Busy Request Time (sec):	Numeric
Sync Requests/sec:	Numeric
NSPI RPC Browse Request Latency (ms):	Numeric
NSPI RPC Request Latency (ms):	Numeric
Referral RPC Request Latency (ms):	Numeric
Control Panel Outbound - Proxy Request Response Time (ms):	Numeric
Control Panel Request Response Time (ms):	Numeric
OWA Unique Users:	Numeric
OWA Requests/sec:	Numeric
OWA Search Time (ms):	Numeric
Web Connection Attempts/sec:	Numeric
Web Connections:	Numeric
Auto Discovery Requests/sec:	Numeric
Webservice Requests/sec:	Numeric
Request Wait Time (ms):	Numeric
Application Restarts:	Numeric
Worker Process Restarts:	Numeric
Queued Requests:	Numeric
Version:	String

Instance

Metric	Data Type
Service	String
Service Name	String
Service Status	String

Data Models

Primary: “Exchange 2016 Client Access Role Metrics”

Instance:

• name: “Exchange 2016 Client Access Role Service Metrics” columns: “Service,Service Name,Service Status”
