Exchange 2016 Transport Role

• version: 1.1
• Compatibility: v 7.7.1
• Requires: Host/IP/CIDR/CSV (Mandatory), Port (Mandatory), Username (Mandatory), Password (Mandatory), Metric Collector Time (Mandatory)
• Operation: monitors the transport pipeline of exchange server
• Change from Last Version: Changes in some python files

Exchange 2016 Transport Role

---

• version: 1.0
• Compatibility: v 7.6.6
• Requires: Host/IP/CIDR/CSV (Mandatory), Port (Mandatory), Username (Mandatory), Password (Mandatory), Metric Collector Time (Mandatory)
• Operation: monitors the transport pipeline of exchange server

Exchange 2016 Transport Role

• Plugin-Metrics:

Metric	Data Type
Version:	String
Message Local Deliveries/sec:	Numeric
Uptime:	String
Mail Submissions/sec:	Numeric
Message Delivery Attempts/sec:	Numeric
Recipient Deliveries/sec:	Numeric
Message Bytes/message:	Numeric
Received Messages/sec:	Numeric
Sent Messages/sec:	Numeric
Dumpster Deletes/sec:	Numeric
Dumpster Items:	Numeric
Dumpster Inserts/sec:	Numeric
Dumpster Size (Bytes):	Numeric
Log Waiting Threads:	Numeric
Log Record Stalls/sec:	Numeric
Database Writes/sec:	Numeric
Database Reads/sec:	Numeric
Database Version buckets Allocations:	Numeric
Log Checkpoint Depth:	Numeric
Log Reads/sec:	Numeric
Log Writes/sec:	Numeric
Message Queue Deliveries/sec:	Numeric
Message Deliveries/sec:	Numeric
Message Submissions/sec:	Numeric
Poison Queue Length:	Numeric
Largest Delivery Queue Length:	Numeric
Aggregate Delivery Queue Length:	Numeric
Active Remote Delivery Queue Length:	Numeric
Active Mailbox Delivery Queue Length:	Numeric
Submission Queue Length:	Numeric
Active Non SMTP Delivery Queue Length:	Numeric
Retry Mailbox Delivery Queue Length:	Numeric
Retry Non SMTP Delivery Queue Length:	Numeric
Retry Remote Delivery Queue Length:	Numeric
Unreachable Queue Length:	Numeric

Instances

Mailbox Queue

Metric	Data Type
Mailbox Queue	String
Mailbox Queue Status	String
Mailbox Queue Incoming Messages	String
Mailbox Queue Outgoing Messages	String
Mailbox Queue Messages	Numeric

Service

Metric	Data Type
Service	String
Service Status	String
Service Name	String

Data Models

Primary: “Exchange 2016 Transport Role Metrics”

Instance:

• name: “Exchange 2016 Transport Role Service Metrics” columns: “Service,Service Name,Service Status”
• name: “Exchange 2016 Transport Role Mailbox Queue Metrics” columns: “Mailbox Queue,Mailbox Queue Status,Mailbox Queue Incoming Messages,Mailbox Queue Outgoing Messages,Mailbox Queue Messages”
