VMware Virtual Machine
- version: 7.9
- Compatibility: v 7.6.4
- Requires: Host/IP/CIDR/CSV (Mandatory), VM Sync (Mandatory), Discover Powered Off ESX/ESXi (Mandatory), Username (Mandatory), Password (Mandatory), Metric Collect Interval (Mandatory)
- Operation: monitors the VMware Virtual Machine.
- version: 7.8
- Compatibility: v 7.6.4
- Requires: Host/IP/CIDR/CSV (Mandatory), VM Sync (Mandatory), Discover Powered Off ESX/ESXi (Mandatory), Username (Mandatory), Password (Mandatory), Metric Collect Interval (Mandatory)
- Operation: monitors the VMware Virtual Machine.
- Change from Last Version: Removed Disk Latency Metric
- version: 7.7
- Compatibility: v 7.6.2
- Requires: Host/IP/CIDR/CSV (Mandatory), VM Sync (Mandatory), Discover Powered Off ESX/ESXi (Mandatory), Username (Mandatory), Password (Mandatory), Metric Collect Interval (Mandatory)
- Operation: monitors the VMware Virtual Machine.
- Change from Last Version: Addition of Flag for Duplication with values YES or NO. Default: NO
- version: 7.6
- Compatibility: v 7.6.0
- Requires: Host/IP/CIDR/CSV (Mandatory), VM Sync (Mandatory), Discover Powered Off ESX/ESXi (Mandatory), Username (Mandatory), Password (Mandatory), Metric Collect Interval (Mandatory)
- Operation: monitors the VMware Virtual Machine.
- version: 7.5
- Compatibility: v 7.5.3
- Requires: Host/IP/CIDR/CSV (Mandatory), VM Sync (Mandatory), Discover Powered Off ESX/ESXi (Mandatory), Username (Mandatory), Password (Mandatory), Metric Collect Interval (Mandatory)
- Operation: monitors the VMware Virtual Machine.
- Plugin-Metrics:
VMware Virtual Machine
| Metric | Data Type |
|---|---|
| CPU (%) | Numeric |
| Memory (%) | Numeric |
| Disk (%) | Numeric |
| CPU (MHz) | Numeric |
| CPU Wait (ms) | Numeric |
| CPU Ready (ms) | Numeric |
| CPU Reserved Capacity (MHz) | Numeric |
| CPU Swap Wait (ms) | Numeric |
| CPU Capacity (MHz) | Numeric |
| Disk I/O (Bytes/sec) | Numeric |
| VMKernel Memory (MB) | Numeric |
| Swap Memory (MB) | Numeric |
| Active Memory (MB) | Numeric |
| Consumed Memory (MB) | Numeric |
| Memory Swap OUT Rate (KBps) | Numeric |
| Memory Capacity (MB) | Numeric |
| Swap OUT Memory (MB) | Numeric |
| Unreserved Memory (MB) | Numeric |
| Heap Memory (MB) | Numeric |
| Connection State | String |
| Reserved Capacity Memory (MB) | Numeric |
| Zero Memory (MB) | Numeric |
| Heap Free Memory (MB) | Numeric |
| Shared Memory (MB) | Numeric |
| Swap IN Memory (MB) | Numeric |
| Memory Swap IN Rate (KBps) | Numeric |
| Overhead Memory (MB) | Numeric |
| Active Write Memory (MB) | Numeric |
| Balloon Memory (MB) | Numeric |
| Granted Memory (MB) | Numeric |
| Network IN Traffic (bps) | Numeric |
| Network OUT Traffic (bps) | Numeric |
| Network Traffic (bps) | Numeric |
| Disk Capacity (MB) | Numeric |
| Free Disk (MB) | Numeric |
| Used Disk (MB) | Numeric |
| Shared Common Memory (MB) | Numeric |
| CPU Usage (MHz) | Numeric |
| System Uptime (Seconds) | Numeric |
| Virtual Processors | Numeric |
| Virtual Machine Memory (MB) | Numeric |
| Virtual Interfaces | Numeric |
| Virtual Disk Volumes | Numeric |
| Virtual Machine | String |
| VM Path | String |
| Guest OS | String |
| Power State | String |
| Power Consumption | Numeric |
| Guest IP | String |
| Guest Host | String |
| VM Tool | String |
| Uptime | String |
Instance Columns:
Disk Volume
| Metric | Data Type |
|---|---|
| Disk Volume | String |
| Disk Volume Capacity (MB) | Numeric |
| Disk Volume Free (MB) | Numeric |
| Disk Volume Used (MB) | Numeric |
| Disk Volume Utilization (%) | Numeric |
Interface
| Metric | Data Type |
|---|---|
| Interface | String |
| Interface IN Traffic (bps) | Numeric |
| Interface OUT Traffic (bps) | Numeric |
| Interface Traffic (bps) | Numeric |
Disk
| Metric | Data Type |
|---|---|
| Disk | String |
| Disk Byte Reads/sec | Numeric |
| Disk Byte Writes/sec | Numeric |
| Disk Writes/sec | Numeric |
| Disk Reads/sec | Numeric |
| Disk Queue Read Latency (ms) | Numeric |
| Disk Issued Commands/sec | Numeric |
| Disk Queue Write Latency (ms) | Numeric |
| Disk Aborted Commands | Numeric |
| Disk I/O Latency (ms) | Numeric |
| Disk Read Latency (ms) | Numeric |
| Disk Write Latency (ms) | Numeric |
| Disk Queue Latency (ms) | Numeric |
Virtual Disk
| Metric | Data Type |
|---|---|
| Virtual Disk | String |
| Virtual Disk Byte Writes/sec | Numeric |
| Virtual Disk Byte Reads/sec | Numeric |
| Virtual Disk Aborted Commands | Numeric |
| Virtual Disk Read Latency (ms) | Numeric |
