ISIS Routing

• version: 8.4
• Compatibility: v 7.7.4
• Requires: Host/IP/CIDR/CSV (Mandatory), Port (Mandatory), Version (Mandatory), Community, Security Level, Authentication Protocol, Privacy Protocol, Security User Name, Authentication Password, Private Password, Metric Collect Interval (Second)
• Operation: Collects information from ISIS routing devices.
• Change from Last Version: Performance Improvement

---

• version: 8.3
• Compatibility: v 7.6.8
• Requires: Host/IP/CIDR/CSV (Mandatory), Port (Mandatory), Version (Mandatory), Community, Security Level, Authentication Protocol, Privacy Protocol, Security User Name, Authentication Password, Private Password, Metric Collect Interval (Second)
• Operation: Collects information from ISIS routing devices.
• Change from Last Version: Improvement: Test Methods added for Demo Server

---

• version: 8.2
• Compatibility: v 7.6.6
• Requires: Host/IP/CIDR/CSV (Mandatory), Port (Mandatory), Version (Mandatory), Community, Security Level, Authentication Protocol, Privacy Protocol, Security User Name, Authentication Password, Private Password, Metric Collect Interval (Second)
• Operation: Collects information from ISIS routing devices.
• Change from Last Version: Improvement: SNMP Polling Capability

---

• version: 8.1
• Compatibility: v 7.6.3
• Requires: Host/IP/CIDR/CSV (Mandatory), Port (Mandatory), Version (Mandatory), Community, Security Level, Authentication Protocol, Privacy Protocol, Security User Name, Authentication Password, Private Password, Metric Collect Interval (Second)
• Operation: Collects information from ISIS routing devices.
• Change from Last Version: Improvement: Polling Enhancement

---

• version: 7.9
• Compatibility: v 7.6.1
• Requires: Host/IP/CIDR/CSV (Mandatory), Port (Mandatory), Version (Mandatory), Community, Security Level, Authentication Protocol, Privacy Protocol, Security User Name, Authentication Password, Private Password, Metric Collect Interval (Second)
• Operation: Collects information from ISIS routing devices.
• Change from Last Version: New Feature: Discovery via SNMP is added

---

• version: 7.8
• Compatibility: v 7.6.1
• Requires: Host/IP/CIDR/CSV (Mandatory), Port (Mandatory), Version (Mandatory), Community, Security Level, Authentication Protocol, Privacy Protocol, Security User Name, Authentication Password, Private Password, Metric Collect Interval (Second)
• Operation: Collects information from ISIS routing devices.
• Change from Last Version: Addition of Flag for Duplication with values YES or NO. Default: NO

---

• version: 7.7
• Compatibility: v 7.6.0
• Requires: Host/IP/CIDR/CSV (Mandatory), Port (Mandatory), Version (Mandatory), Community, Security Level, Authentication Protocol, Privacy Protocol, Security User Name, Authentication Password, Private Password, Metric Collect Interval (Second)
• Operation: Collects information from ISIS routing devices.
• Change from Last Version: Performance Improvement for Polling Functionality

---

• version: 7.6
• Compatibility: v 7.5.3
• Requires: Host/IP/CIDR/CSV (Mandatory), Port (Mandatory), Version (Mandatory), Community, Security Level, Authentication Protocol, Privacy Protocol, Security User Name, Authentication Password, Private Password, Metric Collect Interval (Second)
• Operation: Collects information from ISIS routing devices.
• Plugin-Metrics:

ISIS Routing

Instance Metric	Data Type
Routing Entries	Numeric
Wait Time	String
Max Age	String
System Level	String
Admin State	String
Packet Lost (%)	Numeric
Lost Packets	Numeric

• Instance Metric

Route:

Instance Metric	Data Type
Route	String
Subnet Mask	String
Next Hope	String
Interface Index	Numeric
Route Protocol	String
Metric	Numeric
Last Updated (sec)	Numeric
Last Updated	String
Route Type	String
CIDR	Numeric

Neighbour:

Instance Metric	Data Type
Neighbour	String
Device IP Address	String
Neighbour Protocol	String
Last Up Time	String
Hold Time	String
System Type	String
3Way State	String
State	String
